- Description
- Exterior Protection Sheet Metal:
- CE standard fully enclosed protection
- Saw Feed System:
- 45 degree servo feed
- 0 degree servo feed (Non-optional)
- Electric Appliance:
- Door open automatic power off function
- CE Electrical Safety
- Main drive permanent magnet motor
- Main drive servo motor (Non-optional)
- HMI
- Siemens PLC (Optional)
- Inverter
- Microlubrication system
- Oil mist filter
- Cutting pipe blast device
- Cabinet air conditioner
- LED working light
- Hydraulic:
- Automatic chip conveyor
- Vise pressure regulator
- Power Brush
- Nesting Clamping System
- Oil cooling fan filter
- Automatic lubrication device for guide rail
- Material Feeding:
- Roller type work table
- Simple Roller table (Non-optional)
- Servo Feed
- 1.5M power output material table
- 2M Servo Power output material table (Optional)
- Short material pulling device (third set of clamps)
- 6M power output material table (rectangular material) - (Non-optional)
- 6M power output material table (bar material) - (Non-optional)
- 6M power output material table (Trapped material storage) - (Non-optional)
- Manufacturer
- Specifications
- Custom Freight
JLH 10 in. Circular Sawing Machine C-10PRO
ITEM: 10 in. Circular Sawing Machine
MANUFACTURER: JLH
MODEL: C-10PRO
Manufacturer:
JLH
Machine Type
Machine Category:
Saws
Machine Sub-Category:
Cold/Circular
Material Type:
Metal
Metalworking
Saw Capacity:
10"+
MODEL
|
C-10PRO
|
||
Maximum Cutting Capacity
|
Round |
3.94 - 10.24 in. |
|
Square |
3.94 - 7.87 in. |
||
Saw Blade
|
Speed
|
103.84 - 649.02 fpm |
|
Size
|
33.07 x 0.16 in. |
||
PVD:4/26/160,Kuef:0.15 in. |
|||
Motor Output
|
Saw Blade
|
40.2 hp |
|
Hydraulic
|
7.37 hp |
||
Feed |
7.37 hp |
||
Material Feed
|
3.9 hp |
||
Oil Tank Capacity |
Hydraulic Oil |
33 Gal. |
|
Cutting Liquid |
0.43 Gal. |
||
Machine Flange Size |
φ 80 in. |
||
Voltage
|
Imax(A)480V/60Hz |
68 |
|
Imax(A)220V/60Hz |
148.4 |
||
Bed Height |
36.37 in. |
||
Machine Weight
+ Roller Table |
≈ 26,455 lbs. + 1653 lbs. |
||
Machine Size (LxWxH)
exclude roller table |
118.11 x 117.17 x 110.24 in. |
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
3 YEAR WARRANTY - Mechanical Parts
2 YEAR WARRANTY - Electrical Parts
1 YEAR WARRANTY - Labor
