<p><b>SPECIFICATIONS:</b></p>
<table border="1" cellspacing="0" cellpadding="0" width="520">
<tbody style="text-align: center;">
<tr>
<td width="99" valign="middle" bgcolor="#333333" class="Title_white_bold"><div>
<div align="center"><span style="color: #ffffff;"><strong>MODEL</strong></span></div>
</div></td>
<td valign="middle" bgcolor="#333333" class="Title_white_bold"><div></div></td>
<td width="78" valign="middle" bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: #ffffff;"><strong>2190TE-3</strong></span></div></td>
</tr>
<tr class="TableText_bold">
<td class="Title_white_bold" rowspan="4" valign="middle" bgcolor="#333333"><div>
<div align="center"><span style="color: #ffffff;"><strong>CAPACITY</strong></span></div>
</div></td>
<td class="TableText" valign="middle" bgcolor="#CCCCCC"><div align="center">Swing Over Bed:</div></td>
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div align="center">21-3/8"</div></td>
</tr>
<tr class="TableText_bold">
<td class="TableText" valign="middle" bgcolor="#CCCCCC"><div align="center">Swing Over Cross Slide:</div></td>
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div align="center">15-1/4"</div></td>
</tr>
<tr class="TableText_bold">
<td class="TableText" valign="middle" bgcolor="#CCCCCC"><div align="center">Swing In Gap:</div></td>
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div align="center">28-3/4"</div></td>
</tr>
<tr class="TableText_bold">
<td class="TableText" valign="middle" bgcolor="#CCCCCC"><div align="center">Distance Between Centers</div></td>
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div align="center">86.61"</div></td>
</tr>
<tr class="TableText_bold">
<td class="Title_white_bold" rowspan="3" valign="middle" bgcolor="#333333"><div>
<div align="center"><span style="color: #ffffff;"><strong>HEADSTOCK</strong></span></div>
</div></td>
<td class="TableText" valign="middle" bgcolor="#CCCCCC"><div align="center">Spindle Nose: </div></td>
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div align="center">D1-8</div></td>
</tr>
<tr class="TableText_bold">
<td class="TableText" valign="middle" bgcolor="#CCCCCC"><div align="center">Spindle Bore:</div></td>
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div align="center">3-1/8"</div></td>
</tr>
<tr class="TableText_bold">
<td class="TableText" valign="middle" bgcolor="#CCCCCC"><div align="center">Spindle RPM: </div></td>
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div align="center">26-1500 (12 Steps)</div></td>
</tr>
<tr bgcolor="#CCCCCC" class="TableText">
<td rowspan="2" valign="middle" bgcolor="#333333" class="Title_white_bold"><div>
<div align="center"><span style="color: #ffffff;"><strong>POWER</strong></span></div>
</div></td>
<td valign="middle" class="TableText"><div align="center">Main Motor:</div></td>
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div align="center">12-1/2 HP</div></td>
</tr>
<tr bgcolor="#CCCCCC" class="TableText">
<td valign="middle" class="TableText"><div align="center">Voltage: </div></td>
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div align="center">230V/460V AC ~ 3 PH</div></td>
</tr>
<tr>
<td rowspan="3" valign="middle" bgcolor="#333333" class="Title_white_bold"><div>
<div align="center"><span style="color: #ffffff;"><strong>MEASUREMENT</strong></span></div>
</div></td>
<td valign="middle" bgcolor="#CCCCCC" class="TableText"><div>
<div align="center">Weight </div>
</div></td>
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div align="center">5,700 lbs.</div></td>
</tr>
<tr bgcolor="#CCCCCC" class="TableText">
<td class="TableText" rowspan="2" width="175" valign="middle"><div>
<div align="center">Packing sizes </div>
</div></td>
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div>
<div align="center">114.2" (2900mm) </div>
</div></td>
</tr>
<tr bgcolor="#CCCCCC" class="TableText">
<td valign="middle" bgcolor="#FFFFFF" class="TableText"><div>
<div align="center">45.5" (1155mm) x 68.7" (1745mm) </div>
</div></td>
</tr>
</tbody>
</table>
<p><b><br>FEATURES:</b></p>
<ul><li>Made in Taiwan - High Quality!</li><li><strong>BED:</strong></li><li>One-piece casting base.</li><li>Meehanite casting, vibration stress relieved.</li><li>Induction hardened and precision ground bed ways, precision hand scraped removable gap.</li><li>Foot brake.</li><li>Turcite B coating between bed and carriage.</li><li><strong>GEARBOX:</strong></li><li>Universal type allowing a wide range of inch, metric, M.P., D.P. threads without change gears.</li><li><strong>HEADSTOCK:</strong></li><li>Housing is vibration-absorbent, deflection-free.</li><li>Gears are hardened & MMG or REISHAUER ground.</li><li><strong>HEAVY DUTY SPINDLE:</strong></li><li>Machined from forged alloy steel, hardened ground & dynamically balanced.</li><li>Three point support by high grade precision, machine tool taper roller & ball bearings.</li><li><strong>APRON:</strong></li><li>RIH or LJH wheel can be available on request.</li><li>Integrated automatic control for longitudinal & cross feeds, forward & reverse feeds.</li><li><strong>CARRIAGE AND SLIDE:</strong></li><li>Anti-Float design backlash eliminator fitted in cross slide nut.</li><li>Safety clutch at feed shaft.</li><li>One shot lubrication in carriage & top slide.</li><li>Dual dials supply inch system screw.</li><li>Metric dial supply metric system only.</li><li><strong>SAFETY FEATURES:</strong></li><li>Nylon safety gears in end train.</li><li>Shear pin in leadscrew.</li></ul>
<p><strong>STANDARD EQUIPMENT:</strong></p>
<ul>
<li>12" 3-Jaw Chuck</li>
<li>16" 4-Jaw Chuck</li>
<li>Coolant System</li>
<li>Halogen Light</li>
<li>Full Length Splash Guard</li>
<li>Steady Rest/Follow Rest</li>
<li>4 Way Tool Holder</li>
<li>2 Speed Tail Stock</li>
</ul>
