<p><b>SPECIFICATIONS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr>
<td class="Title_white_bold" width="103" bgcolor="#333333">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>MODEL</strong></span>
</div>
</td>
<td class="TableText" bgcolor="#333333">
<div align="center">
</div>
</td>
<td class="Title_white_bold" width="208" bgcolor="#333333">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>YCL-32120</strong></span>
</div>
</td>
</tr>
<tr>
<td rowspan="10" class="Title_white_bold" width="103" bgcolor="#333333">
<div align="center"><strong> <span style="color: rgb(255, 255, 255);"></span></strong><strong><span style="color: rgb(255, 255, 255);">CAPACITY</span></strong>
</div>
</td>
<td class="TableText" width="201" bgcolor="#CCCCCC">
<div align="center">Swing over bed
</div>
</td>
<td class="TableText">
<div align="center">32"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Swing over cross slide
</div>
</td>
<td class="TableText">
<div align="center">22-1/2"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Swing in gap diameter
</div>
</td>
<td class="TableText">
<div align="center">41"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Length of gap
</div>
</td>
<td class="TableText">
<div align="center">10"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Center Height
</div>
</td>
<td class="TableText">
<div align="center">16"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Distance between centers
</div>
</td>
<td class="TableText">
<div align="center">120"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Width of bed
</div>
</td>
<td class="TableText">
<div align="center">16"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Max. Section of tool
</div>
</td>
<td class="TableText">
<div align="center">1" x 1"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Max. Travel Cross Slide
</div>
</td>
<td class="TableText">
<div align="center">16-1/2"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Max. Travel of Compound Rest
</div>
</td>
<td class="TableText">
<div align="center">9"
</div>
</td>
</tr>
<tr>
<td rowspan="5" class="Title_white_bold" bgcolor="#333333">
<div align="center"><strong><span style="color: rgb(255, 255, 255);">HEADSTOCK</span></strong>
</div>
</td>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Spindle bore
</div>
</td>
<td class="TableText" valign="top">
<div align="center">4-1/8"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Spindle nose
</div>
</td>
<td class="TableText">
<div align="center">D1-8
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Taper of spindle bore
</div>
</td>
<td class="TableText">
<div align="center">F113mm (1:20) / MT5
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Spindle speed step
</div>
</td>
<td class="TableText">
<div align="center">16
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Range of spindle speed
</div>
</td>
<td class="TableText">
<div align="center">25 ~1600rpm
</div>
</td>
</tr>
<tr>
<td rowspan="9" class="Title_white_bold" bgcolor="#333333"><span style="color: rgb(255, 255, 255);"></span>
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>THREADS & FEEDS</strong></span>
</div>
</td>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Leadscrew Pitch
</div>
</td>
<td class="TableText" valign="top">
<div align="center">F40mm x 2T.P.I
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Inch Threads range
</div>
</td>
<td class="TableText">
<div align="center">7/16 ~ 80T.P.I
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Metric Thread Range
</div>
</td>
<td class="TableText">
<div align="center">0.45 ~ 120mm (54 kinds)
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Diametrical pitches range
</div>
</td>
<td class="TableText">
<div align="center">7/8 ~ 160DP (42 kinds)
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Module pitches range
</div>
</td>
<td class="TableText">
<div align="center">0.25 ~ 60MP (46 kinds)
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Cross Feeds Range<br>
in Metric Lead Screw
</div>
</td>
<td class="TableText">
<div align="center">0.044 ~ 1.48mm/rev (25 kinds)
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Cross Feeds Range<br>
in Inch Lead Screw
</div>
</td>
<td class="TableText">
<div align="center">0.00165" ~ 0.05497"/rev (25 kinds)
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Longitudinal Feeds Range<br>
in Metric Lead Screw
</div>
</td>
<td class="TableText">
<div align="center">0.022 ~ 0.74mm/rev (25 kinds)
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Longitudinal Feeds Range<br>
in Inch Lead Screw
</div>
</td>
<td class="TableText">
<div align="center">0.00083" ~ 0.02774"/rev (25 kinds)
</div>
</td>
</tr>
<tr>
<td rowspan="3" class="Title_white_bold" bgcolor="#333333">
<div align="center"><strong><span style="color: rgb(255, 255, 255);">TAILSTOCK</span></strong>
</div>
</td>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Travel of Tailstock Sleeve
</div>
</td>
<td class="TableText">
<div align="center">9-1/4"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Dia. of Tailstock Sleeve
</div>
</td>
<td class="TableText">
<div align="center">F3-1/2"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Morse Taper of Tailstock Sleeve
</div>
</td>
<td class="TableText">
<div align="center">MT5#
</div>
</td>
</tr>
<tr>
<td rowspan="2" class="Title_white_bold" bgcolor="#333333">
<div align="center"><strong><span style="color: rgb(255, 255, 255);">MOTOR</span></strong>
</div>
</td>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Power of Main Motor
</div>
</td>
<td class="TableText">
<div align="center">11Kw (10 hp)
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Power of Coolant Pump
</div>
</td>
<td class="TableText">
<div align="center">0.09Kw (1/8 hp)
</div>
</td>
</tr>
<tr>
<td rowspan="4" class="Title_white_bold" bgcolor="#333333">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>DIMENSION & WEIGHT</strong></span>
</div>
</td>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Overall Dimension (L x W x H)
</div>
</td>
<td class="TableText">
<div align="center">—</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Packing Size (L x W x H)
</div>
</td>
<td class="TableText">
<div align="center">—</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Net Weight
</div>
</td>
<td class="TableText">
<div align="center"> —
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div align="center">Gross Weight
</div>
</td>
<td class="TableText">
<div align="center">—</div>
</td>
</tr>
</tbody>
</table>
<p><strong><br>STANDARD ACCESSORIES:</strong></p>
<ul> <li>3-Jaw Chuck</li> <li>4-Jaw Chuck</li> <li>Face plate</li> <li>Steady Rest</li> <li>Follow Rest</li> <li>Threading Chasing Dial</li> <li>113mm (1:20) MT5 Sleeve and MT5 Center</li> <li>Oil Gun</li> <li>One set of wrenches</li> <li>Operational manual</li> <li>Drive plate</li> <li>4-way tool post</li> <li>Rapid travel</li> <li>Splash guard</li> <li>Taper turning attachment</li></ul>
