<p><b>SPECIFICATIONS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr bgcolor="#333333" class="Title_white_bold">
<td class="TableText"><div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><b>MODEL</b></span></div>
</div></td>
<td width="257" class="TableText"><div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><b>GML-1790T</b></span></div>
</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" width="257" class="TableText"><div align="center">Max. swing over bed </div></td>
<td class="TableText"><div align="center">17 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" width="257" class="TableText"><div align="center">Max. length of workpiece</div></td>
<td class="TableText"><div align="center">90 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Max. swing over cross slide</div></td>
<td class="TableText"><div align="center">9-1/2 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Max. Swing in gap </div></td>
<td class="TableText"><div align="center">25-1/2 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Width of Bed</div></td>
<td class="TableText"><div align="center">12 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Effective length in gap to spindle</div></td>
<td class="TableText"><div align="center">6 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Effective length in gap to chuck jaws</div></td>
<td class="TableText"><div align="center">3-1/2 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Spindle bore </div></td>
<td class="TableText"><div align="center">3-1/8” , D1-8 </div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Taper of spindle center </div></td>
<td class="TableText"><div align="center">M.T.# 6 w/reducing sleeve MT6/MT5</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Spindle speeds</div></td>
<td class="TableText"><div align="center">40-2,000 rpm / 12 steps</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Longitudinal feeds</div></td>
<td class="TableText"><div align="center">0.002-0.03 IPR, 35 kinds</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Cross feeds</div></td>
<td class="TableText"><div align="center">0.0008-0.011 IPR, 35 kinds</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Inch threads </div></td>
<td class="TableText"><div align="center">4-56 TPI, 36 kinds</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Metric threads </div></td>
<td class="TableText"><div align="center">0.5-7.0 mm ,17 kinds</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" width="257" class="TableText"><div align="center">Max. travel of top slide</div></td>
<td class="TableText"><div align="center">5 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Max. travel of cross slide</div></td>
<td class="TableText"><div align="center">11 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Spindle length w/o chuck</div></td>
<td class="TableText"><div align="center">17 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Leadscrew length X TPI </div></td>
<td class="TableText"><div align="center">1-1/4 in. x 4 TPI </div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Diameter of tailstock quill</div></td>
<td class="TableText"><div align="center">2-3/4 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Max. travel of tailstock quill </div></td>
<td class="TableText"><div align="center">5-7/8 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Taper of tailstock quill center</div></td>
<td class="TableText"><div align="center">M.T. #4</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Main motor</div></td>
<td class="TableText"><div align="center">7-1/2HP, 220V or 440V, 3 phase</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Amperage Draw</div></td>
<td class="TableText"><div align="center">220V/ 35A , 440V/20A</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Coolant pump motor </div></td>
<td class="TableText"><div align="center">1/8 HP, 220V, or 440V, 3 phase, <br>
2 Gal coolant</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Machine Oil </div></td>
<td class="TableText"><div align="center">#30 weight Machine oil, 5 Gallons</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Machine Weight, approx.</div></td>
<td class="TableText"><div align="center">4,750 lbs.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Overall Dimensions, LxWxH</div></td>
<td class="TableText"><div align="center">139 x 41 x 57 in.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Shipping dimensions, LxWxH</div></td>
<td class="TableText"><div align="center">140 x 38 x 63 in.</div></td>
</tr>
</tbody>
</table>
<p><b>FEATURES:</b></p>
<ul>
<li>Made in Taiwan-100% made in Taiwan, by top manufacturer with very high level of quality</li>
<li><strong>5 years industrial warranty for parts for all Taiwan lathes </strong></li>
<li>One piece solid casting base, Meehanite high performance cast iron </li>
<li>Machine bed is made of Meehanite casting – high performance cast iron </li>
<li>ISO 9001 certified</li>
<li>Large spindle bore 3-1/8” </li>
<li>Heavy Duty spindle D1-8 </li>
<li>Heavy Duty guideway width 12” </li>
<li>Spindle speeds from 40-2,000 rpm, 12 speeds</li>
<li>Threading and feeding rate change without changing gears </li>
<li>Spindle is balanced, hardened and precision ground</li>
<li>Spindle is supported at 3-point by high precision bearings </li>
<li>All gears and shafts are hardened and precision ground </li>
<li>Guideways induction hardened and precision ground</li>
<li>Automatic lubrication system in headstock and feed box </li>
</ul>
<p><b>STANDARD EQUIPMENT:</b></p>
<ul>
<li><u>Free CARMAR DRO, installed </u><u> </u></li>
<li>Automatic kick-out longitudinal carriage stop system<u></u></li>
<li>10” 3-jaw chuck with top reversible jaws, direct mount </li>
<li>16” Face plate </li>
<li>9” steady rest with roller jaws </li>
<li>4” follow rest with roller jaws </li>
<li>Removeable gap</li>
<li>4-way tools post </li>
<li>Foot brake </li>
<li>LED Work light </li>
<li>Coolant system</li>
<li>Full length rear splash guard </li>
<li>Dead centers </li>
<li>Thread chasing dial </li>
<li>Reducing sleeve MT6/MT5 for spindle </li>
<li>Tool box and leveling pads </li>
</ul>
<p><b>OPTIONAL ITEMS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520" class="TableText1">
<tbody style="text-align: center;">
<tr bgcolor="#333333" class="Title_white1">
<td width="121" class="optional_accessories"><div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><b>PART #
</b></span></div>
</div></td>
<td width="315" bgcolor="#333333"><div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><b>ITEM
</b></span></div>
</div></td>
<td width="76" bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: rgb(255, 255, 255);"><b>PRICE</b></span></div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">—</div></td>
<td><div align="center">Taper attachment, installed </div></td>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">$2,950.00</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">—</div></td>
<td><div align="center">5-C Hand lever type collet closer, free install </div></td>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">$2,250.00</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">3900-0014</div></td>
<td><div align="center">33 pc 5C collet set, from 1/16”-1-1/16” by 32nd</div></td>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">$595.00</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"> <div align="center">3900-5260</div></td>
<td><div align="center">ALORIS type QC tool post, 6 pcs </div></td>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">$975.00</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">3900-5004</div></td>
<td><div align="center">Live Center for tailstock </div></td>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">$265.00</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">3900-5005</div></td>
<td><div align="center">Live Center for tailstock </div></td>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">$295.00</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">—</div></td>
<td><div align="center">Chuck Guard</div></td>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">$795.00</div></td>
</tr>
</tbody>
</table>
