<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr>
<td class="TableText" width="257" valign="middle" bgcolor="#cccccc">
<div class="TableText" align="center">Cutting capacity: mild steel
</div>
</td>
<td class="TableText" width="257" valign="middle">
<div align="center">10 ft x 14 Ga
</div>
</td>
</tr>
<tr>
<td class="TableText" valign="middle" bgcolor="#cccccc">
<div align="center">Cutting capacity: stainless steel
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">10 ft x 18 Ga
</div>
</td>
</tr>
<tr>
<td class="TableText" width="257" valign="middle" bgcolor="#cccccc">
<div align="center">Blade length
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">10 ft 1 in.
</div>
</td>
</tr>
<tr>
<td class="TableText" valign="middle" bgcolor="#cccccc">
<div align="center">Strokes per minute adjustable
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">14-18
</div>
</td>
</tr>
<tr>
<td class="TableText" valign="middle" bgcolor="#cccccc">
<div align="center">Throat Depth
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">16
in.
</div>
</td>
</tr>
<tr>
<td class="TableText" valign="middle" bgcolor="#cccccc">
<div align="center">Worktable Height
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">30-1/2 in.
</div>
</td>
</tr>
<tr>
<td class="TableText" valign="middle" bgcolor="#cccccc">
<div align="center">Front support arm
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">24 in.
</div>
</td>
</tr>
<tr>
<td class="TableText" valign="middle" bgcolor="#cccccc">
<div align="center">Manual back gauge
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">26 in. manual
</div>
</td>
</tr>
<tr>
<td class="style13" valign="middle" bgcolor="#cccccc">
<div class="TableText" align="center">
<div align="center">Blade rake angle
</div>
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">1.5 degree
</div>
</td>
</tr>
<tr>
<td class="TableText" valign="middle" bgcolor="#cccccc">
<div align="center">oil tank capacity
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">20 gal.
</div>
</td>
</tr>
<tr>
<td class="TableText" valign="middle" bgcolor="#cccccc">
<div align="center">Main motor
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">5-1/2 HP, 220V/440V, 3-Phase
</div>
</td>
</tr>
<tr>
<td class="TableText" valign="middle" bgcolor="#cccccc">
<div align="center">Machine Weight
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">5,200 lbs.
</div>
</td>
</tr>
<tr>
<td class="TableText" valign="middle" bgcolor="#cccccc">
<div align="center">Machine Dimensions
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">139 x 35 x 52 in.
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul>
<li>Taiwan machines</li>
<li>ISO 9001 certified </li>
<li>HD all steel construction for maximum rigidity</li>
<li>German logic quiet Rexroth hydraulic system </li>
<li>Adjustable stroke from 16-20 strokes per minute</li>
<li>60" long squaring arm with inch / mm scale</li>
<li>Spring hold-downs </li>
<li>high grade carbon/chrome alloy steel blades and hardened to 62 hrc, 2-edge indexable upper blade and 2-edge indexable bottom blade</li>
<li>Full length with full view finger guard </li>
<li>Front supports and (2) side gauges </li>
<li>Safety type foot pedal control </li>
<li>Jog, single continuous auto operation modes</li>
<li>One year warranty for parts</li>
<li>*This machine is compatible with a phase converter. Please note that the phase converter must be installed by GMC Machine Tools to ensure warranty coverage. Once the machine is received and the phase converter is installed by us, it will be ready for use. For more information or if you have any further questions or need assistance, feel free to contact us</li>
</ul>
<p><strong>STANDARD EQUIPMENT:</strong>
</p>
<ul>
<li>26" manual back gauge with inch/metric dual scale & one side operated hand wheel </li>
<li>60" long squaring arm with inch / mm scale</li>
<li>2 each 24" front support arms </li>
<li>2 each 14" Side gauges with inlaid inch/metric dual scale</li>
<li>Spring independent hold-downs </li>
<li>full length finger guard </li>
<li>Removable safety foot pedal control </li>
<li>One set of blades </li>
</ul>
<p><b>OPTIONAL ITEMS:</b></p>
<ul>
<li>Safety fence for enclosure of the back side of the machine………… $1,150.00 </li>
<li>Special blade set for stainless steel for HS-1014MD…... $2,350.00 </li>
</ul>
