<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr class="TableText">
<td bgcolor="#cccccc" width="257" valign="middle" class="TableText1">
<div align="center"><span class="TableText">Table Size</span>
</div>
</td>
<td width="257" valign="middle" class="TableText1">
<div align="center"><span class="TableText">10 x 50 in.</span>
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" width="257" valign="middle" class="TableText1">
<div align="center"><span class="TableText">Table Load Capacity</span>
</div>
</td>
<td valign="middle" class="TableText1">
<div align="center" class="TableText">
<div align="center">727 lbs
</div>
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center"><span class="TableText">X Axis Travel</span>
</div>
</td>
<td valign="middle" class="TableText">
<div align="center" class="TableText">
<div align="center">33 in.
</div>
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center">X Travel with power feed
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">28-3/4 in.
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center"><span class="TableText">Y Axis Travel</span>
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">12-1/2 in.with power feed
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center"><span class="TableText"> Z Axis Travel</span>
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">16 in.
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center">Max. distance spindle to table
</div>
</td>
<td valign="middle" class="TableText1">
<div align="center">1-11/16 -17-5/8 in.
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center">Max. distance spindle to column
</div>
</td>
<td valign="middle" class="TableText1">
<div align="center">17-1/4 in.
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center">Min. distance spindle to column
</div>
</td>
<td valign="middle" class="TableText1">
<div align="center">8-1/4 in.
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center"><span class="TableText">Spindle Taper Type</span>
</div>
</td>
<td valign="middle" class="TableText1">
<div align="center" class="TableText">
<div align="center">R-8
</div>
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center"><span class="TableText">AC Spindle Motor</span>
</div>
</td>
<td valign="middle" class="TableText1">
<div align="center" class="TableText">
<div align="center">3 HP, 220V, 3-phase
or 1-phase
</div>
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center">Variable spindle speeds
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">60-4,000 rpm, Inverter Drive
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center"><span class="TableText">Quill ( Spindle ) diameter</span>
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">3-3/8 in.
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center"><span class="TableText">Quill ( Spindle ) travel</span>
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">5 in.
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center" class="TableText">
<div align="center">Ram travel
</div>
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">17 in.
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center">Table T-slot size
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">5/8 in. x 3 slots
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center">Head Swivel, Right to Left
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">90 degree
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center">Head Tilting
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">45 degree
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center">Machine Dimensions
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">66 x 63 x 87 in.
</div>
</td>
</tr>
<tr class="TableText">
<td bgcolor="#cccccc" valign="middle" class="TableText1">
<div align="center"><span class="TableText">Machine Weight</span>, approx.
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">2,880 lbs
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul class="TableText">
<li>Made in Taiwan </li>
<li>“Meehanite” casting </li>
<li>Turcite “B” coating on X/Y ways like CNC mills </li>
<li>ISO 9001 certified</li>
<li>Inverter drive variable spindle speeds from 60-4,000 rpm </li>
<li>Heavy duty 3 HP AC spindle motor with 5HP Delta inverter drive </li>
<li>Heavy Duty high grade castings </li>
<li>Hardened and ground ways, dovetail ways on X and Z , square ways on Y knee </li>
<li>Hardened and ground table and Ground table T-slots </li>
<li>Precision ground ACME Leadscrews</li>
<li>Chromed ground quill ( spindle ) </li>
<li>Chromed dials </li>
<li>Adjustable ways </li>
<li>Hand brake on mill head </li>
<li>Tilting and rotating head </li>
<li>Manual or automatic quill feeds 0.0015” , 0.003”, 0.006” per spindle revolution</li>
<li>One shot lube system </li>
<li>front and rear rubber chip guards, and (1) manual draw bar </li>
<li>Tool box kit and leveling pads </li>
<li>Power source 220V, 3-phase or 220V, 1-phase, either way works</li>
<li>One year industrial warranty for parts </li>
</ul>
<p><strong>STANDARD EQUIPMENT: </strong>
</p>
<ul class="TableText">
<li>2 axis CARMAR DRO installed on X and Y </li>
<li>Table power feeds X and Y installed </li>
<li>One shot lube </li>
<li>Draw bar </li>
<li>Rubber way covers</li>
<li>Tool box </li>
</ul>
<p><b>OPTIONAL ITEMS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520" class="TableText">
<tbody style="text-align: center;">
<tr bgcolor="#333333" class="Title_white">
<td width="96" class="optional_accessories">
<div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>PART # </strong></span>
</div>
</div>
</td>
<td width="338" bgcolor="#333333">
<div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>ITEM</strong></span>
</div>
</div>
</td>
<td width="78" bgcolor="#333333" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>PRICE</strong></span>
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">—
</div>
</td>
<td>
<div align="center">Coolant System
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$550.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">COOL-PAN
</div>
</td>
<td>
<div align="center">Base coolant/chip drop pan
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$450.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">900-0021
</div>
</td>
<td>
<div align="center">6" angle lock vise with swivel base
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$595.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">900-0001
</div>
</td>
<td>
<div align="center">52 pcs clamping kit, 1/2”-13NC stud, 5/8” T-slot
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$295.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">900-0007
</div>
</td>
<td>
<div align="center">11 pcs R 8 collets set, 1/8” – 7/8”
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$275.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">PAM-300HD
</div>
</td>
<td>
<div align="center">Rotary Phase converter, 7HP, USA, <br>
for single phase conversion
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$1,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">Mill package #3
</div>
</td>
<td>
<div align="center">Mill package #3, incl 6" vise # 3900-2103, <br>
Collet set #3900-0007, <br>
Clamping Kit #3900-0001,<br>
20pc Titanium end mill set #8000-0020, <br>
29pc Titanium drill bit set #5000-0001
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$1,295.00
</div>
</td>
</tr>
</tbody>
</table>
