<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr bgcolor="#333333" class="Title_white_bold">
<td class="TableText1">
<div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>MODEL</strong></span>
</div>
</div>
</td>
<td width="270" class="TableText1">
<div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>OCL-47160G
</strong></span>
</div>
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" width="244" class="TableText1">
<div align="center">Max. swing over bed
</div>
</td>
<td class="TableText1">
<div align="center">47 in.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Distance Between Centers
</div>
</td>
<td class="TableText1">
<div align="center">160 in.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Max. swing over cross slide
</div>
</td>
<td class="TableText1">
<div align="center">33-1/2 in. (830mm)
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Width of Bed
</div>
</td>
<td class="TableText1">
<div align="center">24-1/4 in. (692mm)
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Spindle bore
</div>
</td>
<td class="TableText1">
<div align="center">12-1/8 in. (310mm)
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Spindle Nose
</div>
</td>
<td class="TableText1">
<div align="center">A 2-20
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Spindle speeds
</div>
</td>
<td class="TableText1">
<div align="center">4-420rpm, 12 steps
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Max. weight of workpiece
</div>
</td>
<td class="TableText1">
<div align="center">9,000 lbs.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Longitudinal Auto Feeds
</div>
</td>
<td class="TableText1">
<div align="center">0.004" – 0.055" IPR, 40 kinds
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Cross Slide Auto Feeds
</div>
</td>
<td class="TableText1">
<div align="center">0.004" – 0.022" IPR, 40 kinds
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Inch threads
</div>
</td>
<td class="TableText1">
<div align="center">59 – 1 TPI, 35 kinds
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Metric threads
</div>
</td>
<td class="TableText1">
<div align="center">0.5-18mm , 34 kinds
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Max. travel of top slide
</div>
</td>
<td class="TableText1">
<div align="center">13-3/4 in.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Longitudinal rapid traverse
</div>
</td>
<td class="TableText1">
<div align="center">12 ft/min
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Cross rapid traverse
</div>
</td>
<td class="TableText1">
<div align="center">6 ft/min
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" width="244" class="TableText1">
<div align="center">Top slide rapid traverse
</div>
</td>
<td class="TableText1">
<div align="center">3 ft/min
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Diameter of tailstock quill
</div>
</td>
<td class="TableText1">
<div align="center">5 in.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Max. travel of tailstock quill
</div>
</td>
<td class="TableText1">
<div align="center">12 in.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Taper of tailstock quill center
</div>
</td>
<td class="TableText1">
<div align="center">MT 6
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Main Motor
</div>
</td>
<td class="TableText1">
<div align="center">50 HP, 220V or 440V, 3 phase
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Rapid traverse motor
</div>
</td>
<td class="TableText1">
<div align="center">1/2 HP, 220V or 440V, 3 phase
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Lubrication pump motor
</div>
</td>
<td class="TableText1">
<div align="center">1/8 HP, 220V or 440V, 3 phase
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Coolant pump motor
</div>
</td>
<td class="TableText1">
<div align="center">1/8 HP, 220V or 440V , 3 phase
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Weight, approx.
</div>
</td>
<td class="TableText1">
<div align="center">27,580 lbs.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText1">
<div align="center">Overall Dimensions LWH
</div>
</td>
<td class="TableText1">
<div align="center">264 x 79 x 82 in.
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p><p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p><br><ul>
<li>Made in Taiwan</li>
<li>ISO 9001 certified</li>
<li>Super large spindle bore 12-1/8" (310mm)</li>
<li>Rapid traverse on carriage longitudinal, cross slide and top slide</li>
<li>Automatic feeding on carriage longitudinal, cross slide</li>
<li>2 speed Tailstock</li>
<li>solid cast iron machine base</li>
<li>Heavy Duty guideway width 27-1/4" </li>
<li>Heavy Duty main motor 50 HP </li>
<li>16 spindle speeds from 9-300rpm </li>
<li>Spindle is balanced, hardened and precision ground </li>
<li>All gears and shafts are hardened and precision ground </li>
<li>Guideways induction hardened and precision ground</li>
<li>Automatic lubrication system in headstock and feed box</li>
<li>One year industrial warranty for parts </li>
<li><strong><u>*DISCLAIMER</u></strong>: Please note this machine<u> is incompatible with the use of a rotary phase converter</u>. Any attempt to purchase, install, or employ one, whether carried out by you or a professional service company, <u>will automatically void the warranty.</u> It is crucial to understand that any such actions are entirely the responsibility of the buyer. </li>
<li>**This disclaimer is intended to clearly convey that the utilization of a rotary phase converter to power or operate this machine is not supported </li>
</ul>
<p><strong> STANDARD EQUIPMENT: </strong>
</p>
<ul>
<li>4-way tools post </li>
<li>Work light </li>
<li>Coolant system</li>
<li> (1) dead center for tailstock </li>
<li>Thread chasing dial </li>
<li>Tool box</li>
</ul>
<p>Optional Items:</p>
<table cellspacing="0" cellpadding="0" border="1" width="520" class="TableText1">
<tbody style="text-align: center;">
<tr bgcolor="#333333" class="Title_white1">
<td width="92" class="optional_accessories">
<div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>PART #
</strong></span>
</div>
</div>
</td>
<td width="339" bgcolor="#333333">
<div align="center" class="Title_white_bold">
<span style="color: rgb(255, 255, 255);"><strong></strong></span>
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>ITEM
</strong></span>
</div>
</div>
</td>
<td width="81" bgcolor="#333333" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>PRICE</strong></span>
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">SR10-OCL
</div>
</td>
<td>
<div align="center">Large steady rest 3" to 10-1/2"
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$2,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">SR-18-OCL
</div>
</td>
<td>
<div align="center">Large steady rest 6" to 18-1/2"
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$9,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">SR23-OCL
</div>
</td>
<td>
<div align="center">Large steady rest 10" to 23"
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$10,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">SR36-OCL
</div>
</td>
<td>
<div align="center">Large steady rest 21" to 36"
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$13,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">FR10-OCL
</div>
</td>
<td>
<div align="center">Follow rest, 4" – 10"
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$13,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">4J30-OCL
</div>
</td>
<td>
<div align="center">Heavy duty 30" 4-jaw chuck
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$32,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">LC-OCL
</div>
</td>
<td>
<div align="center">Roller live center for tailstock MT6
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$9,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">TA-OCL
</div>
</td>
<td>
<div align="center">Taper turning attachment, free installation
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$17,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">MTS
</div>
</td>
<td>
<div align="center">Motorized top slide
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$1,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">QC
</div>
</td>
<td>
<div align="center">Quick change toolpost( fixed type)
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$6,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">—
</div>
</td>
<td>
<div align="center">Grinder
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$7,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">—
</div>
</td>
<td>
<div align="center">Machine centers from 390" to 630"
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$POR
</div>
</td>
</tr>
</tbody>
</table>
