<p><b>SPECIFICATIONS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr class="TableText" height="14">
<td colspan="2" bgcolor="#cccccc">
<div align="center">Max. swing over cross slide
</div>
</td>
<td width="263" height="14">
<div align="center">6"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td colspan="2" bgcolor="#cccccc">
<div align="center">Distance between centers
</div>
</td>
<td height="14">
<div align="center">18"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td colspan="2" bgcolor="#cccccc">
<div align="center">Max. swing over bed
</div>
</td>
<td height="14">
<div align="center">11"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td colspan="2" bgcolor="#cccccc">
<div align="center">Swing over carriage
</div>
</td>
<td height="14">
<div align="center">9"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td width="92" rowspan="6" bgcolor="#cccccc" class="TableText">
<div align="center"><span class="TableText">Spindle Capacities</span>
</div>
</td>
<td width="157" bgcolor="#cccccc">
<div align="center">with 3-jaw chuck
</div>
</td>
<td height="14">
<div align="center">6"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td width="157" bgcolor="#cccccc">
<div align="center">with expanding collets
</div>
</td>
<td height="14">
<div align="center">3"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td width="157" bgcolor="#cccccc">
<div align="center">with round 5C collets
</div>
</td>
<td height="14">
<div align="center">1-1/16"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td width="157" bgcolor="#cccccc">
<div align="center">with hexagon 5C collets
</div>
</td>
<td height="14">
<div align="center">7/8"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td width="157" bgcolor="#cccccc">
<div align="center">with Square 5C collets
</div>
</td>
<td height="14">
<div align="center">3/4"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td width="157" bgcolor="#cccccc">
<div align="center">with step chucks
</div>
</td>
<td height="14">
<div align="center">1-1/16" to 6"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Spindle nose diameter
</div>
</td>
<td height="14">
<div align="center">2.189”
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Spindle nose ID/OD
</div>
</td>
<td height="14">
<div align="center">5C / 4 degree taper
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Spindle thru hole
</div>
</td>
<td height="14">
<div align="center">1-1/4”
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Bar stock diameter with 5C closer
</div>
</td>
<td height="14">
<div align="center">1-1/16”
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Variable spindle speeds
</div>
</td>
<td height="14">
<div align="center">0-4,000 rpm (5C)<br>
0-3,000 rpm (with 6” 3-jaws chuck)
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Leadscrew diameter / pitch
</div>
</td>
<td height="14">
<div align="center">1” / 8TPI
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Carriage power feed speed range
</div>
</td>
<td height="14">
<div align="center">5/16” to 7” /min
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Cross slide power feed range
</div>
</td>
<td height="14">
<div align="center">3/16” to 4” / min
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Cross slide travel
</div>
</td>
<td height="14">
<div align="center">6"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Quick change compound slide travel
</div>
</td>
<td height="14">
<div align="center">0.1"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Compound slide travel
</div>
</td>
<td height="14">
<div align="center">3"
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Inch threads
</div>
</td>
<td height="14">
<div align="center">11-118 TPI , 36 kinds
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Metric threads
</div>
</td>
<td height="14">
<div align="center">0.275-2.7mm, 36 kinds
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Tailstock quill diameter
</div>
</td>
<td height="14">
<div align="center">1-3/8”
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Tailstock quill taper
</div>
</td>
<td height="14">
<div align="center">MT# 2
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Tailstock quill travel
</div>
</td>
<td height="14">
<div align="center">3-3/4”
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Spindle motor ( inverter drive )
</div>
</td>
<td height="14">
<div align="center">3HP, 220V, 3 phase
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">DC feeding motor
</div>
</td>
<td height="14">
<div align="center">110V, 70 W
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Inverter drive for gear box
</div>
</td>
<td height="14">
<div align="center">—
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Coolant pump
</div>
</td>
<td height="14">
<div align="center">1/8HP, 220V, 3 phase
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Machine weight , approx
</div>
</td>
<td height="14">
<div align="center">2,530 lbs.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" colspan="2" bgcolor="#cccccc">
<div align="center">Machine dimensions, LxWxH
</div>
</td>
<td height="14">
<div align="center">73 x 30 x 67 in.
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<p><b>FEATURES:</b></p>
<ul>
<li>Made in Taiwan </li>
<li>ISO 9001 certified</li>
<li>Spindle run-out within 0.00005” ( 50 millionths inch ) </li>
<li>Turcite-B coating on guideways </li>
<li>3HP Yaskawa inverter drive spindle motor </li>
<li>Infinity Yaskawa inverter drive spindle speeds from 0-4,000 rpm </li>
<li>Easy to read digital readout on actual spindle rpm speeds </li>
<li>Electric variable automatic feeding control on carriage and cross slide </li>
<li>Quick change tool post slide for threading </li>
<li>Dual range inch/metric quick change gear box for model # GMCTL-618EVS </li>
<li>Digital control and inverter drive gearbox ( no change gear ) for #GMCTL-618E, easy cutting threads, variable inch / metric threads range </li>
<li>Automatic thread length control w/ fine adjustable stops for accurate threading </li>
<li>36 kinds of inch threads, and 36 kinds of metric threads</li>
<li>Spindle is balanced, hardened and precision ground</li>
<li>High precision pre-loaded angular contact bearings for spindle </li>
<li>Lubrication system for headstock, feed box, ways and leadscrews </li>
<li>Power 220V, 3 phase ( 220V, 1 phase is optional ) </li>
<li>One year industrial warranty for parts </li>
<li>This disclaimer is intended to clearly convey that the utilization of a rotary phase converter to power or operate this machine is not supported </li>
<li><strong><u>DISCLAIMER</u></strong>: Please note this machine<u> is incompatible with the use of a rotary phase converter</u>. Any attempt to purchase, install, or employ one, whether carried out by you or a professional service company, <u>will automatically void the warranty.</u> It is crucial to understand that any such actions are entirely the responsibility of the buyer. </li>
</ul>
<p><strong> STANDARD EQUIPMENT: </strong>
</p>
<ul>
<li>5C collet closer installed</li>
<li>Quick change gear box </li>
<li>8” drive plate with drive dog</li>
<li> Dual inch / metric dials </li>
<li>CARMAR DRO, Installed</li>
<li>Coolant system </li>
<li>Halogen work light </li>
<li> Tool box with tools </li>
</ul><p><b>OPTIONAL ITEMS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520" class="TableText1">
<tbody style="text-align: center;">
<tr bgcolor="#333333" class="Title_white1">
<td width="92" class="optional_accessories">
<div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>PART # </strong></span>
</div>
</div>
</td>
<td width="339" bgcolor="#333333">
<div align="center" class="Title_white_bold">
<span style="color: rgb(255, 255, 255);"><strong></strong></span>
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>ITEM </strong></span>
</div>
</div>
</td>
<td width="81" bgcolor="#333333" class="Title_white_bold"><span style="color: rgb(255, 255, 255);"><strong></strong></span>
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>PRICE</strong></span>
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">TA-618EVS
</div>
</td>
<td>
<div align="center">Taper Attachment, Installed
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$3,150.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">3900-0014
</div>
</td>
<td>
<div align="center">33 pc 5C collet set, from 1/16 to 1-1/16” by 32ndth
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$595.00
</div>
</td>
</tr>
</tbody>
</table>
