<p><b>SPECIFICATIONS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Max. swing over bed
</div>
</td>
<td width="257" height="14" class="TableText">
<div align="center">20-1/2 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Max. length of workpiece
</div>
</td>
<td height="14" class="TableText">
<div align="center">60 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Max. swing over cross slide
</div>
</td>
<td height="14" class="TableText">
<div align="center">13 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Max. Swing in gap
</div>
</td>
<td height="14" class="TableText">
<div align="center">29-1/8 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Width of Bed
</div>
</td>
<td height="14" class="TableText">
<div align="center">12 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Effective length in gap to spindle
</div>
</td>
<td height="14" class="TableText">
<div align="center">6 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Effective length in gap to chuck jaws
</div>
</td>
<td height="14" class="TableText">
<div align="center">3-1/2 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Spindle bore
</div>
</td>
<td height="14" class="TableText">
<div align="center">3-1/8 in., D1-8
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Taper of spindle center
</div>
</td>
<td height="14" class="TableText">
<div align="center">M.T.# 6 w/ reducing sleeve MT6/MT5
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Spindle speeds
</div>
</td>
<td height="14" class="TableText">
<div align="center">40-2,000 rpm / 12 steps
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Longitudinal feeds
</div>
</td>
<td height="14" class="TableText">
<div align="center">0.002-0.03 IPR, 35 kinds
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Cross feeds
</div>
</td>
<td height="14" class="TableText">
<div align="center">0.0008-0.011 IPR, 35 kinds
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Inch threads
</div>
</td>
<td height="14" class="TableText">
<div align="center">4-56 TPI, 36 kinds
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Metric threads
</div>
</td>
<td height="14" class="TableText">
<div align="center">0.5-7.0 mm ,17 kinds
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Max. travel of top slide
</div>
</td>
<td height="14" class="TableText">
<div align="center">5 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Max. travel of cross slide
</div>
</td>
<td height="14" class="TableText">
<div align="center">11 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Spindle length w/o chuck
</div>
</td>
<td height="14" class="TableText">
<div align="center">17 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Leadscrew length X TPI
</div>
</td>
<td height="14" class="TableText">
<div align="center">1-1/4 in.x 4 TPI
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Diameter of tailstock quill
</div>
</td>
<td height="14" class="TableText">
<div align="center">2-3/4 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Max. travel of tailstock quill
</div>
</td>
<td height="14" class="TableText">
<div align="center">5-7/8 in.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Taper of tailstock quill center
</div>
</td>
<td height="14" class="TableText">
<div align="center">M.T. #4
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Main motor
</div>
</td>
<td height="14" class="TableText">
<div align="center">7-1/2HP, 220V, 3 phase</div>
</td>
</tr>
<tr height="14">
<td height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Amperage Draw
</div>
</td>
<td height="14" class="TableText">
<div align="center">35A</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Coolant pump motor
</div>
</td>
<td height="14" class="TableText">
<div align="center">1/8 HP, 220V, or 440V, 3 phase, 2 Gal coolant
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Machine Oil
</div>
</td>
<td height="14" class="TableText">
<div align="center">#30 weight Machine oil, 5 Gallons
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Machine weight, approx.
</div>
</td>
<td height="14" class="TableText">
<div align="center">4,150 lbs.
</div>
</td>
</tr>
<tr height="14">
<td width="257" height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Overall dimensions, LxWxH
</div>
</td>
<td height="14" class="TableText">
<div align="center">105 x 41 x 59 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" class="TableText">
<div align="center">Machine Shipping Dimensions LWH
</div>
</td>
<td height="14" class="TableText">
<div align="center">110 x 38 x 66 in.
</div>
</td>
</tr>
</tbody>
</table>
<p></p>
<p><strong>FEATURES:</strong></p>
<ul>
<li>Made in Taiwan-100% made in Taiwan, by top manufacturer with very high level of quality</li>
<li>5 years industrial warranty for parts for all Taiwan lathes </li>
<li><strong>One piece solid casting base, Meehanite high performance cast iron </strong></li>
<li><strong>Machine bed is made of Meehanite casting – high performance cast iron</strong><strong> </strong></li>
<li>ISO 9001 certified</li>
<li>Large spindle bore 3-1/8” </li>
<li>Heavy Duty spindle D1-8 </li>
<li>Heavy Duty guideway width 12” </li>
<li>Spindle speeds from 40-2,000 rpm, 12 speeds</li>
<li>Threading and feeding rate change without changing gears </li>
<li>Spindle is balanced, hardened and precision ground</li>
<li>Spindle is supported at 3-point by high precision bearings </li>
<li>All gears and shafts are hardened and precision ground </li>
<li>Guideways induction hardened and precision ground</li>
<li>Automatic lubrication system in headstock and feed box </li>
<li><strong><u>DISCLAIMER: </u></strong>Please note this machine<u> is incompatible with the use of a rotary phase converter</u>. Any attempt to purchase, install, or employ one, whether carried out by you or a professional service company, <u>will automatically void the warranty.</u> It is crucial to understand that any such actions are entirely the responsibility of the buyer.</li>
<li>This disclaimer is intended to clearly convey that the utilization of a rotary phase converter to power or operate this machine is not supported. </li>
</ul>
<p><strong> STANDARD ACCESSORIES: </strong>
</p>
<ul>
<li><u>Free CARMAR DRO, installed </u><u> </u></li>
<li>Automatic kick-out longitudinal carriage stop system<u></u></li>
<li>10” 3-jaw chuck with top reversible jaws, direct mount </li>
<li>16” Face plate </li>
<li>9” steady rest with roller jaws </li>
<li>4” follow rest with roller jaws </li>
<li>Removeable gap</li>
<li>4-way tools post </li>
<li>Foot brake </li>
<li>LED Work light </li>
<li>coolant system</li>
<li>full length rear splash guard </li>
<li>Dead centers </li>
<li>Thread chasing dial </li>
<li>Reducing sleeve MT6/MT5 for spindle </li>
<li>Tool box and leveling pads </li>
</ul>
<p><b>Optional items:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520" class="TableText1">
<tbody style="text-align: center;">
<tr bgcolor="#333333" class="Title_white1">
<td width="121" class="optional_accessories">
<div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>PART # </strong></span>
</div>
</div>
</td>
<td width="315" bgcolor="#333333">
<div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>ITEM</strong></span>
</div>
</div>
</td>
<td width="76" bgcolor="#333333" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>PRICE</strong></span>
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">—
</div>
</td>
<td>
<div align="center">Taper Attachment, Installed
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$2,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">—
</div>
</td>
<td>
<div align="center">5-C Hand lever type collet closer, free install
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$2,250.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">3900-0014
</div>
</td>
<td>
<div align="center">33 pc 5C collet set, from 1/16 to 1-1/16” by 32ndth
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$595.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">3900-5260
</div>
</td>
<td>
<div align="center">6pc ALORIS type QC tool post set
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$975.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">3900-5004
</div>
</td>
<td>
<div align="center">Live Center for tailstock
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$265.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">3900-5005
</div>
</td>
<td>
<div align="center">Live Center for headstock
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$295.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">—
</div>
</td>
<td>
<div align="center">Chuck Guard
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$795.00
</div>
</td>
</tr>
</tbody>
</table>
