<p><b>SPECIFICATIONS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Max. swing over bed </span>
</div>
</td>
<td width="257" height="14">
<div align="center">14 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center" class="TableText">
<div align="center">Max. length of workpiece
</div>
</div>
</td>
<td height="14">
<div align="center">40 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc">
<div align="center">Max Length of cutting
</div>
</td>
<td height="14">
<div align="center">34 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Max. swing over cross slide </span>
</div>
</td>
<td height="14">
<div align="center">8-5/8 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Max. Swing over gap </span>
</div>
</td>
<td height="14">
<div align="center">20-1/4 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Width of Bed </span>
</div>
</td>
<td height="14">
<div align="center">7-1/2 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Spindle bore </span>
</div>
</td>
<td height="14">
<div align="center">1-1/2 in., D1-4
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Taper of spindle center </span>
</div>
</td>
<td height="14">
<div align="center">MT# 5 (MT5/MT3 with reducing sleeve)
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Spindle speeds </span>
</div>
</td>
<td height="14">
<div align="center">45-1,800 rpm, 12 steps
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Longitudinal feeds </span>
</div>
</td>
<td height="14">
<div align="center">.0016-.00368IPR, 40 kinds
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Cross feeds</span>
</div>
</td>
<td height="14">
<div align="center">.0008-.00122IPR, 40 kinds
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Inch threads </span>
</div>
</td>
<td height="14">
<div align="center">4-56 TPI, 32 kinds
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Metric threads </span>
</div>
</td>
<td height="14">
<div align="center">0.4-7.0 mm , 32 kinds
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Max. travel of top slide </span>
</div>
</td>
<td height="14">
<div align="center">3-1/2 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Max. travel of cross slide </span>
</div>
</td>
<td height="14">
<div align="center">6-5/16 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc">
<div align="center">Longitudinal leadscrew
</div>
</td>
<td height="14">
<div align="center">Dia 1 in. / 4TPI
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Diameter of tailstock quill </span>
</div>
</td>
<td height="14">
<div align="center">1-9/16 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Max. travel of tailstock quill </span>
</div>
</td>
<td height="14">
<div align="center">3-1/2 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Taper of tailstock quill center </span>
</div>
</td>
<td height="14">
<div align="center">M.T. # 3
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc">
<div align="center">Oil for headstock/ Gear box/Apron
</div>
</td>
<td height="14">
<div align="center">#30 weight machine oil, TEXACO regal R&O/100, 3 Gal.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Main motor </span>with 5HP inverter drive
</div>
</td>
<td height="14">
<div align="center">3HP, 220v, 1-phase
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc">
<div align="center">Amperage Draw
</div>
</td>
<td height="14">
<div align="center">10 Amp
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Coolant pump </span>
</div>
</td>
<td height="14">
<div align="center">1/16HP, 220V, 1phase, water base coolant
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Machine weight, approx. </span>
</div>
</td>
<td height="14">
<div align="center">1,930 lbs.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc" width="257">
<div align="center"><span class="TableText">Overall dimensions, LxWxH </span>
</div>
</td>
<td height="14">
<div align="center">73 x 35 x 59 in.
</div>
</td>
</tr>
<tr class="TableText" height="14">
<td height="14" bgcolor="#cccccc">
<div align="center">Machine Shipping Dimensions LWH
</div>
</td>
<td height="14">
<div align="center">77 x 30 x 61 in.
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 5 YEAR</strong> – Parts
</p>
<p></p>
<ul>
<li>Made in Taiwan-100% made in Taiwan, by top manufacturer with very high level of quality</li>
<li>ISO 9001 certified</li>
<li>Machine bed is made of high tensile cast iron FC25 </li>
<li>With free CARMAR DRO installed </li>
<li>Full Geared-head precision Engine Lathe with foot brake </li>
<li>Quick-change gearbox with fast and easy threading set up </li>
<li>Main motor 3HP, 220V, 1phase </li>
<li>Spindle bore 1 1/2” </li>
<li>Heavy Duty spindle D1-4</li>
<li>Heavy Duty guideway width 7-1/2” </li>
<li>Variable spindle speeds from 45-1,800 rpm </li>
<li>32 kinds of inch threads, and 32 kinds of metric threads </li>
<li>Spindle is balanced, hardened and precision ground </li>
<li>All gears and shafts are hardened and precision ground </li>
<li>Guideways induction hardened and precision ground</li>
<li>Automatic lubrication system in headstock and feed box </li>
<li>5 years industrial warranty for parts for all Taiwan lathes </li>
<li><strong><u>DISCLAIMER: </u></strong>Please note this machine<u> is incompatible with the use of a rotary phase converter</u>. Any attempt to purchase, install, or employ one, whether carried out by you or a professional service company, <u>will automatically void the warranty.</u> It is crucial to understand that any such actions are entirely the responsibility of the buyer.</li>
<li>This disclaimer is intended to clearly convey that the utilization of a rotary phase converter to power or operate this machine is not supported. </li>
</ul>
<p><strong> STANDARD EQUIPMENT: </strong>
</p>
<ul>
<li>Free CARMAR DRO installed </li>
<li>6" 3-jaw chuck with set reversible jaws</li>
<li>10" Face plate </li>
<li>4" Steady rest with roller jaws </li>
<li>2" Follow rest with roller jaws </li>
<li>4-position carriage stop </li>
<li>Foot brake</li>
<li>Coolant system</li>
<li>LED work light </li>
<li>Removable gap </li>
<li>4-way tools post </li>
<li>Full length splash guard </li>
<li>(1) dead center and (1) reducing sleeve </li>
<li>Thread chasing dial </li>
<li>Tool box with leveling pads </li>
</ul>
<p><b>Optional items:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520" class="TableText1">
<tbody style="text-align: center;">
<tr bgcolor="#333333" class="Title_white1">
<td width="121" class="optional_accessories">
<div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>PART #
</strong></span>
</div>
</div>
</td>
<td width="315" bgcolor="#333333">
<div align="center" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>ITEM</strong></span>
</div>
</div>
</td>
<td width="76" bgcolor="#333333" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>PRICE</strong></span>
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">5C
</div>
</td>
<td>
<div align="center">5-C Hand lever type collet closer, free install
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$1,650.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">3900-0014
</div>
</td>
<td>
<div align="center">33 pc 5C collet set, from 1/16 to 1-1/16” by 32ndth
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$595.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">3900-5920
</div>
</td>
<td>
<div align="center">6pc ALORIS type quick change toolpost BXA (wedge)
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$725.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">—
</div>
</td>
<td>
<div align="center">Taper Attachment, Installed
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$1,950.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">3900-5003
</div>
</td>
<td>
<div align="center">Live Center MT3
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$175.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">3700-0102
</div>
</td>
<td>
<div align="center">1/2" Drill chuck
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$75.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">3700-0153
</div>
</td>
<td>
<div align="center">1/2" Drill chuck arbor
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$75.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">—
</div>
</td>
<td>
<div align="center">Chuck guard
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$375.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">—
</div>
</td>
<td>
<div align="center">Travel guard for Toolpost
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$475.00
</div>
</td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">Lathe package #1
</div>
</td>
<td>
<div align="center">Lathe package #1 includes:<br>
5pc indexable carbide turning set# 2003-0004, <br>
1/2 drill chuck # 3700-0102, <br>
Chuck arbor # 3700-0153 and <br>
29pc Titanium drill bit set #5000-0001T
</div>
</td>
<td bgcolor="#CCCCCC" class="optional_accessories">
<div align="center">$595.00
</div>
</td>
</tr>
</tbody>
</table>
