<table width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr>
<td rowspan="5" class="TableText" width="70" bgcolor="#cccccc">
<div align="center">Working Capacity
</div>
</td>
<td rowspan="4" class="TableText" width="79" bgcolor="#cccccc">
<div align="center">In Mild Steel
</div>
</td>
<td class="TableText" width="114" bgcolor="#cccccc">
<div align="center">Drilling
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">32mm (1-1/4")
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Face Mill
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">76mm (3")
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">End Mill
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">20mm (3/4")
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Tapping (Optional)
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">16mm (5/8")
</div>
</td>
</tr>
<tr>
<td colspan="2" class="TableText" bgcolor="#cccccc">
<div align="center">In Light Alloy
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">32mm (1-1/4")
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">Taper
</div>
</td>
<td class="TableText" width="247" valign="middle">
<div align="center">MT3 or R8
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">Stroke
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">130mm
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">Depth
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">205mm
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">Table Size
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">730 x 210mm (28.7" x 8.26")
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">X Travel
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">460mm
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">Y Travel
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">190mm
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">Column Diameter
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">Ø115mm
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">No. of Slot
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">4
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">T Slot Size
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">16 x 26mm
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">Main Motor
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">1.5 HP, 110V, 1PH
</div>
</td>
</tr>
<tr>
<td rowspan="2" class="TableText" bgcolor="#cccccc">
<div align="center">Speed
</div>
</td>
<td colspan="2" class="TableText" bgcolor="#cccccc">
<div align="center">1 Speed Motor (Standard)
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">60Hz / 150-3000<br>
50Hz / 125-2500 (12 speeds)
</div>
</td>
</tr>
<tr>
<td colspan="2" class="TableText" bgcolor="#cccccc">
<div align="center">2 Speed Motor (Optional)
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">60Hz / 75-3000<br>
50Hz / 62-2500 (24 speeds)
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">Packing Dimensions (without Stand)
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">32" x 30" x 46" (810 x 740 x 1150mm)
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">Net Weight
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">505 lbs. (230kg)
</div>
</td>
</tr>
<tr>
<td colspan="3" class="TableText" bgcolor="#cccccc">
<div align="center">Gross Weight
</div>
</td>
<td class="TableText" valign="middle">
<div align="center">560 lbs. (255kg)
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications and design are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul>
<li>This machine has, several uses, such as surface cutting, drilling, milling, and also can be equipped with an electric switch for tapping.</li>
<li>This machine is of fine quality, can be operated easily, and it is not limited to skilled operators.</li>
<li> The drilling and milling operation can be performed by two methods:
<ul>
<li>Hand operation, which makes quick drilling.</li>
<li> Worm gear feed operation, which makes slow milling.</li>
</ul>
</li>
<li>Bronze adjustable nuts, which adjust the thread clearance and reduce the wear. They also make screws rotated smoothly and increase the thread accuracy.</li>
<li>Whole column which makes this machine strong, stable, and also keep the high accuracy.</li>
<li>Head of tough cast ensures its accuracy lasting and enduring through the treatment of precise boring cylinder, grinding, and internal stress relief.</li>
<li>To adjust belt and change speed, new pulley cover is easy to open the cover</li>
</ul>
<p><b>OPTIONAL ITEMS - CALL FOR PRICE:</b></p>
<ul>
<li>Power down (spindle) feed</li>
<li>Tapping switch</li>
<li>Forward & Reverse switch</li>
<li>Collet chuck</li>
<li>Work light</li>
<li>Cabinet stand</li>
<li>Extension</li>
<li>Column Clamping kits</li>
</ul>
