<p><b>SPECIFICATIONS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Max. Punching Diameter</div></td>
<td width="214" class="TableText"><div align="center">1-1/16"</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Max. Punching Thickness</div></td>
<td class="TableText"><div align="center">5/8" *<br>
1/4" for 304 Stainless Steel</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Max. Output </div></td>
<td class="TableText"><div align="center">52 Tons</div></td>
</tr>
<tr>
<td width="199" bgcolor="#cccccc" class="TableText"><div align="center">Max. Throat Depth</div></td>
<td width="214" class="TableText"><div align="center">4-5/16"</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Hole Making Time</div></td>
<td class="TableText"><div align="center">Punching Time 11.8 sec.<br>
Returning Time 5.7 sec.</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Allowable Max. Pressure</div></td>
<td class="TableText"><div align="center">10,000 psi</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Weight</div></td>
<td class="TableText"><div align="center">66 lbs.</div></td>
</tr>
</tbody>
</table>
<p><span class="style12">*1" and 1-1/16" punch requires the use of a split lock nut (UHA9936-0) and reduces the maximum thickness to 9/16"<br></span></p>
<p>In case of mild steel maximum punching thickness must be decided based on the equation of 0.8 x punching diameter. For details see the instruction manual.</p>
<ul> <li>Double-acting hydraulic system allows automatic and inching (manual mode) operation.</li> </ul>
<p><strong>ACCESSORIES INCLUDED:</strong></p>
<ul> <li>Hose Kit Assembly</li> <li>Hose Cord Assembly</li> <li>Spanner</li> <li>Spanner 12</li> <li>Sub Handle Assembly</li> <li>Chip Guard Ass'y</li> <li>Tool Box</li> <li>22mm Punch and Die mounted on machine</li> <li>4mm Allen Wrench</li><li>5mm Allen Wrench</li></ul>
<p><b>OPTIONAL ITEMS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520" class="TableText1">
<tbody style="text-align: center;">
<tr bgcolor="#333333" class="Title_white1">
<td width="114" class="optional_accessories"><div align="center" class="Title_white_bold"><span style="color: rgb(255, 255, 255);"><b>PART #</b></span></div></td>
<td width="400" bgcolor="#333333"><div align="center" class="Title_white_bold"><span style="color: rgb(255, 255, 255);"><b>ITEM</b></span></div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">HPD-05</div></td>
<td><div align="center">Hydraulic Power Unit for HS Series Punchers<br>
115V; 10,000 PSI operating pressure<b><br>$4,600.00</b></div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">UHA9936-0</div></td>
<td><div align="center">Split Lock Nut for 1" and 1-1/16" Punch: <b>$99.00</b></div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">TA99037-0</div></td>
<td><div align="center">Lock Nut Assembly for 25mm Punch: <b>$65.00</b></div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">TW-40</div></td>
<td><div align="center">Spring Balancer for HS11/HS07: <b>$425.00</b></div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">TBO2141-0</div></td>
<td><div align="center">Foot Switch Relay Assembly: <b>$450.00</b></div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="optional_accessories"><div align="center">—</div></td>
<td><div align="center">Round Punches and Dies for HS/HA Series <br>
- See Attachments Tab, Call for Price</div></td>
</tr>
</tbody>
</table>
