<table class="TableText" width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr>
<td class="Title_white_bold" bgcolor="#333333">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>MODEL</strong></span>
</div>
</td>
<td class="Title_white_bold" width="257" bgcolor="#333333">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>HVBS-712V</strong></span>
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">STOCK#
</div>
</td>
<td>
<div align="center">JT9-415559
</div>
</td>
</tr>
<tr>
<td width="257" bgcolor="#cccccc">
<div align="center">Round Capacity at 90° (in.)
</div>
</td>
<td>
<div align="center">7
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Round Capacity at 45° (in.)
</div>
</td>
<td>
<div align="center">4-1/2
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Rectangle Capacity at 90° (in.)
</div>
</td>
<td>
<div align="center">1 (H) x 12 (W)<br>
2 (H) x 11-1/4 (W)<br>
4 (H) x 11 (W)<br>
7 (H) x 10-3/8 (W)
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Rectangle Capacity at 45° (in.)
</div>
</td>
<td>
<div align="center">6-1/2 (H) x 4-1/2 (W)
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Square Capacity at 90° (in.)
</div>
</td>
<td>
<div align="center">7 x 7
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Square Capacity at 45° (in.)
</div>
</td>
<td>
<div align="center">4-1/2 x 4-1/2
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Throat Depth (in.)
</div>
</td>
<td>
<div align="center">7
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Vertical Tables (in.)
</div>
</td>
<td>
<div align="center">9-7/16 x 10
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Vise Swivels (deg.)
</div>
</td>
<td>
<div align="center">45
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Blade Size (in.)
</div>
</td>
<td>
<div align="center">3/4 x .032 x 93
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Blade Wheel Diameter (in.)
</div>
</td>
<td>
<div align="center">11-3/4
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Blade Speed (SFPM)
</div>
</td>
<td>
<div align="center">80 - 255
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Bed Height (in.) without Wheels
</div>
</td>
<td>
<div align="center">22-1/4
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Motor/Electrics
</div>
</td>
<td>
<div align="center">3/4HP, 115/230V, 1-Ph
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Prewired
</div>
</td>
<td>
<div align="center">115V
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Overall Dimensions (LxWxH /in.)
</div>
</td>
<td>
<div align="center">48 x 17 x 40
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Net Weight (lbs.)
</div>
</td>
<td>
<div align="center">368
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Gross Weight (lbs.)
</div>
</td>
<td>
<div align="center">400
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 2 YEAR</strong>
</p>
<ul>
<li>Sealed hardened and ground gear drive</li>
<li>Heavy casted iron bow and bed</li>
<li>Improved wider stand with built-in storage cabinet and chip tray</li>
<li>Blade wheels are made of flanged cast iron</li>
<li>Following strict guidelines and electrical requirements, this JET bandsaw is CSA/US certified for added safety</li>
<li> UL-Listed switches</li>
<li>Blade tensioning guides</li>
<li> Auto shut-off after cut</li>
<li>Speed changes are now done with the turn of a knob, no need to change belts</li>
<li>Four 8" rubber wheels for ease of movement</li>
<li>Tool-less quick lock vise with preset mitering positions at 15, 30 & 45°</li>
<li>Tool-less quick change vise miters to 45°</li>
<li>Multi-position blade guide enhance use in vertical position and increases the throat capacity from 4" to 8"</li>
<li>Side-eccentric shaft and ball bearing: rear-ball bearing blade guides</li>
<li>Cast-mounted hydraulic downfeed for ease of cut</li>
<li>Adjustable hydraulic feed system</li>
<li>Vertical 10" x 12" work table</li>
<li>Large 10" x 12" infeed table assembly extends the support area and can be used in either horizontal or vertical positions</li>
</ul>
<p><strong>STANDARD EQUIPMENT:</strong>
</p>
<ul>
<li>Tool-less quick lock vise with preset mitering positions at 15, 30 & 45°</li>
<li>Multi-position blade guide</li>
<li>Improved wider base with built-in storage</li>
<li>Infeed table assembly</li>
<li> Four 8" rubber wheels for ease of movement</li>
<li>Micro adjustable tool-less material stop allows for quicker set-up and accurate repeatability</li>
<li>Bi-metal 5/8T Blade</li>
<li>Coolant pump with 1-gallon tank, 1/8HP, single-phase motor complete with hose, flexible nozzle, shut-off valve, tank and baffle</li>
</ul>
