<table width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr>
<td class="Title_white_bold" bgcolor="#333333">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>MODEL</strong></span>
</div>
</td>
<td class="Title_white_bold" width="257" bgcolor="#333333">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>837</strong></span>
</div>
</td>
</tr>
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div align="center">Diameter of column
</div>
</td>
<td class="TableText">
<div align="center">8.25"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Max distance from column to spindle
</div>
</td>
<td class="TableText">
<div align="center">37.40"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Min distance from column to spindle
</div>
</td>
<td class="TableText">
<div align="center">8.625"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Travel of spindle head
</div>
</td>
<td class="TableText">
<div align="center">28.75"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Max distance from base to spindle end
</div>
</td>
<td class="TableText">
<div align="center">47.625"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Min distance from base to spindle end
</div>
</td>
<td class="TableText">
<div align="center">13.75"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Elevating height of arm
</div>
</td>
<td class="TableText">
<div align="center">25.56"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Effective area of table
</div>
</td>
<td class="TableText">
<div align="center">23-7/16” x 17-23/32” x 14-31/32"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Dimensions of base
</div>
</td>
<td class="TableText">
<div align="center">49-5/8” x 25-3/16” x 6-9/32"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Drilling capacity steel
</div>
</td>
<td class="TableText">
<div align="center">1.25"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Drilling capacity cast iron
</div>
</td>
<td class="TableText">
<div align="center">1.97"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Tapping steel
</div>
</td>
<td class="TableText">
<div align="center">0.875"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Tapping cast iron
</div>
</td>
<td class="TableText">
<div align="center">0.875"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Boring capacity (steel):
</div>
</td>
<td class="TableText">
<div align="center">2.75"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Boring capacity (cast iron):
</div>
</td>
<td class="TableText">
<div align="center">4.17"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Taper hole sppindle
</div>
</td>
<td class="TableText">
<div align="center">MT #4
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Stroke of spindle
</div>
</td>
<td class="TableText">
<div align="center">8.25"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Spindle speeds (rpm x steps)
</div>
</td>
<td class="TableText">
<div align="center">88, 154, 282, 455, 796, 1500 x 6 steps
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Spindle feeds (rev. x steps)
</div>
</td>
<td class="TableText">
<div align="center">0.002”, 0.0035”, 0.0059” x 3 steps
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Main motor
</div>
</td>
<td class="TableText">
<div align="center">2 HP, 3 phase
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Elevating motor
</div>
</td>
<td class="TableText">
<div align="center">1 HP
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Clamping motor
</div>
</td>
<td class="TableText">
<div align="center">—
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Coolant pump
</div>
</td>
<td class="TableText">
<div align="center">1/8 HP
</div>
</td>
</tr>
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div align="center">Machine height from floor
</div>
</td>
<td class="TableText">
<div align="center">91.38"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Shipping Dimensions
</div>
</td>
<td class="TableText">
<div align="center">71" x 33" x 86"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Net Weight
</div>
</td>
<td class="TableText">
<div align="center">2,860 lbs.
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div align="center">Shipping Weight
</div>
</td>
<td class="TableText">
<div align="center">3,190 lbs.
</div>
</td>
</tr>
</tbody>
</table>
<p>Design and Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul>
<li>Power elevating motor arm with an anti-fall safety device</li>
<li>Hardened and precision ground arm ways</li>
<li>High speed gears are made of Nickel-Chrome steel and through the heat treatment process and precision grinding</li>
<li>Extra auxiliary dial for spindle feed depth indication to review the momental feed depth of spindle</li>
<li>Special mechanism for spindle balance to avoid the defect on breaking of balance spring</li>
<li>Manual clamping of column, arm, and head</li>
<li>Built-in work light</li>
<li>Built-in coolant system</li>
</ul>
<p><strong> STANDARD ACCESSORIES: </strong>
</p>
<ul>
<li>Plain box table</li>
<li>Work light</li>
<li>Coolant system</li>
</ul>
