<p><b>SPECIFICATIONS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr>
<td width="103" bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: rgb(255, 255, 255);"><b>MODEL</b></span></div></td>
<td bgcolor="#333333" class="TableText"><div align="center"></div></td>
<td width="208" bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: rgb(255, 255, 255);"><b>YCL-2660</b></span></div></td>
</tr>
<tr>
<td width="103" rowspan="10" bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: rgb(255, 255, 255);"><strong> </strong><strong>CAPACITY</strong></span></div></td>
<td width="201" bgcolor="#CCCCCC" class="TableText"><div align="center">Swing over bed</div></td>
<td class="TableText"><div align="center">26"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Swing over cross slide</div></td>
<td class="TableText"><div align="center">17-1/4"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Swing in gap diameter</div></td>
<td class="TableText"><div align="center">36"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Length of gap</div></td>
<td class="TableText"><div align="center">10"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Center Height</div></td>
<td class="TableText"><div align="center">13"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Distance between centers</div></td>
<td class="TableText"><div align="center">60"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Width of bed</div></td>
<td class="TableText"><div align="center">16"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Max. Section of tool</div></td>
<td class="TableText"><div align="center">1" x 1"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Max. Travel Cross Slide</div></td>
<td class="TableText"><div align="center">14-1/2"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Max. Travel of Compound Rest</div></td>
<td class="TableText"><div align="center">9"</div></td>
</tr>
<tr>
<td rowspan="5" bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: rgb(255, 255, 255);"><strong>HEADSTOCK</strong></span></div></td>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Spindle bore</div></td>
<td valign="top" class="TableText"><div align="center">4-1/8"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Spindle nose</div></td>
<td class="TableText"><div align="center">D1-8</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Taper of spindle bore</div></td>
<td class="TableText"><div align="center">Φ113mm (1:20) / MT5</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Spindle speed step</div></td>
<td class="TableText"><div align="center">16</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Range of spindle speed</div></td>
<td class="TableText"><div align="center">25 ~1600rpm</div></td>
</tr>
<tr>
<td rowspan="9" bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: rgb(255, 255, 255);"><strong>THREADS & FEEDS</strong></span></div></td>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Leadscrew Pitch</div></td>
<td valign="top" class="TableText"><div align="center">Φ40mm x 2T.P.I</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Inch Threads range</div></td>
<td class="TableText"><div align="center">7/16 ~ 80T.P.I</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Metric Thread Range</div></td>
<td class="TableText"><div align="center">0.45 ~ 120mm (54 kinds)</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Diametrical pitches range</div></td>
<td class="TableText"><div align="center">7/8 ~ 160DP (42 kinds)</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Module pitches range</div></td>
<td class="TableText"><div align="center">0.25 ~ 60MP (46 kinds)</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Cross Feeds Range<br>
in Metric Lead Screw</div></td>
<td class="TableText"><div align="center">0.044 ~ 1.48mm/rev (25 kinds)</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Cross Feeds Range<br>
in Inch Lead Screw</div></td>
<td class="TableText"><div align="center">0.00165" ~ 0.05497"/rev (25 kinds)</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Longitudinal Feeds Range<br>
in Metric Lead Screw</div></td>
<td class="TableText"><div align="center">0.022 ~ 0.74mm/rev (25 kinds)</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Longitudinal Feeds Range<br>
in Inch Lead Screw</div></td>
<td class="TableText"><div align="center">0.00083" ~ 0.02774"/rev (25 kinds)</div></td>
</tr>
<tr>
<td rowspan="3" bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: rgb(255, 255, 255);"><strong>TAILSTOCK</strong></span></div></td>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Travel of Tailstock Sleeve</div></td>
<td class="TableText"><div align="center">9-1/4"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Dia. of Tailstock Sleeve</div></td>
<td class="TableText"><div align="center">Φ3-1/2"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Morse Taper of Tailstock Sleeve</div></td>
<td class="TableText"><div align="center">MT5#</div></td>
</tr>
<tr>
<td rowspan="2" bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: rgb(255, 255, 255);"><strong>MOTOR</strong></span></div></td>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Power of Main Motor</div></td>
<td class="TableText"><div align="center">11Kw (10 hp)</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Power of Coolant Pump</div></td>
<td class="TableText"><div align="center">0.09Kw (1/8 hp)</div></td>
</tr>
<tr>
<td rowspan="4" bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: rgb(255, 255, 255);"><strong>DIMENSION & WEIGHT</strong></span></div></td>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Overall Dimension (L x W x H)</div></td>
<td class="TableText"><div align="center">126.4" x 48.4" x 63" <br>
(3210 x 1230 x 1600)</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Packing Size (L x W x H)</div></td>
<td class="TableText"><div align="center">127.5" x 45" x72.4" <br>
(3240 x 1140 x 1840)</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Net Weight</div></td>
<td class="TableText"><div align="center">6,746 lbs. (3060kgs)</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Gross Weight</div></td>
<td class="TableText"><div align="center">7,782 lbs. (3530kgs)</div></td>
</tr>
</tbody>
</table>
<p><strong><br>STANDARD ACCESSORIES:</strong></p>
<ul><li>3-Jaw Chuck</li><li>4-Jaw Chuck</li><li>Face plate</li><li>Steady Rest</li><li>Follow Rest</li><li>Threading Chasing Dial</li><li>113mm (1:20) MT5 Sleeve and MT5 Center</li><li>Oil Gun</li><li>One set of wrenches</li><li>Operational manual</li><li>Drive plate</li><li>4-way tool post</li><li>Rapid travel</li><li>Splash guard</li><li>Taper turning attachment</li></ul>
