<p><b>SPECIFICATIONS:</b></p>
<table border="1" cellspacing="0" cellpadding="0" width="520">
<tbody style="text-align: center;">
<tr class="Title_white1" bgcolor="#333333">
<td class="Title_white_bold"><div class="Title_white_bold1"><span style="color: rgb(255, 255, 255);"><strong>MODELS</strong></span> </div></td>
<td class="TableText1" bgcolor="#333333"></td>
<td class="TableText1" width="118"><div><span style="color: rgb(255, 255, 255);"><strong><span class="Title_white_bold">YCL-1660KGY</span></strong></span> </div></td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="6" width="94" bgcolor="#333333"><div><span style="color: rgb(255, 255, 255);"><strong> </strong><strong>CAPACITY</strong></span> </div></td>
<td class="TableText1" width="179" bgcolor="#CCCCCC"><div>Swing over bed </div></td>
<td class="TableText1"><div>16" (410mm) </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div align="center">Swing Over Cross Slide</div></td>
<td class="TableText1"><div align="center">10"</div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Swing in gap </div></td>
<td class="TableText1"><div>23-1/4" (590mm) </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Distance between centers </div></td>
<td class="TableText1"><div>60" </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Center height </div></td>
<td class="TableText1"><div>42.2" (1073mm)</div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Width of bed </div></td>
<td class="TableText1"><div>10" </div></td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="4" bgcolor="#333333"><div><span style="color: rgb(255, 255, 255);"><strong>HEADSTOCK</strong></span> </div></td>
<td class="TableText1" bgcolor="#CCCCCC"><div>Spindle nose </div></td>
<td class="TableText1" valign="top"><div>D1-6 </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Spindle nose </div></td>
<td class="TableText1"><div>2" (52mm) </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Taper of spindle bore </div></td>
<td class="TableText1"><div>No.6 Morse </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Range of spindle speeds </div></td>
<td class="TableText1"><div>16 changes 45-1800r/min </div></td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="10" bgcolor="#333333"><div><span style="color: rgb(255, 255, 255);"><strong>THREADS & FEEDS</strong></span> </div></td>
<td class="TableText1" bgcolor="#CCCCCC"><div>Max. travel of compound rest </div></td>
<td class="TableText1"><div>4" </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Max. travel of cross slide </div></td>
<td class="TableText1"><div>8-1/4" </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Leadscrew pitch </div></td>
<td class="TableText1"><div>4 T.P.I. </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Max. Section of tool </div></td>
<td class="TableText1"><div>13/16" </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Longitudinal feeds range </div></td>
<td class="TableText1"><div>0.05-1.7mm/rev (0.002"-0.067"/rev) </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Cross feeds range </div></td>
<td class="TableText1"><div>0.025-0.85mm/rev (0.001"-0.0335"/rev )</div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Metric threads range </div></td>
<td class="TableText1"><div>39 kinds 0.2-14mm </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Inch threads range </div></td>
<td class="TableText1"><div>45 kinds 272 T.P.I. </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Diametrical pitches range </div></td>
<td class="TableText1"><div>21 kinds 8-44 D.P. </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Module pitches range </div></td>
<td class="TableText1"><div>18 kinds 0.3-3.5 M.P. </div></td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="3" bgcolor="#333333"><div><span style="color: rgb(255, 255, 255);"><strong>TAILSTOCK</strong></span> </div></td>
<td class="TableText1" bgcolor="#CCCCCC"><div>Travel of tailstock sleeve </div></td>
<td class="TableText1"><div>4-3/4" </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Morse taper of tailstock sleeve </div></td>
<td class="TableText1"><div>No. 4 Morse </div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Cross adjustment </div></td>
<td class="TableText1"><div>±12" (±13mm) </div></td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="2" bgcolor="#333333"><div><strong><span style="color: rgb(255, 255, 255);">MOTOR</span></strong> </div></td>
<td class="TableText1" bgcolor="#CCCCCC"><div>Power of main motor </div></td>
<td class="TableText1"><div>6 HP / 3 PH, 220V</div></td>
</tr>
<tr>
<td class="TableText1" bgcolor="#CCCCCC"><div>Power of coolant pump </div></td>
<td class="TableText1"><div>1/8 HP, 3 ph </div></td>
</tr>
<tr>
<td class="Title_white_bold" bgcolor="#333333"><div><span style="color: rgb(255, 255, 255);"><strong>WEIGHT & DIMENSIONS</strong></span> </div></td>
<td class="TableText1" bgcolor="#CCCCCC"><div>Gross Weight </div></td>
<td class="TableText1"><div>4,500 lbs. </div></td>
</tr>
</tbody>
</table>
<p><b><br>FEATURES:</b></p>
<ul>
<li> No change gear in tool box.</li>
<li>6 Horse Power Heavy Duty Motor</li>
<li> The thread category complete, not only cutting metric thread and imperial thread, but also cutting diametric thread and module thread.</li>
<li>Minimum Cross feed 0.01mm/rev, Minimum Longitudinal feed 0.046mm/rev.</li>
</ul>
<p><strong>STANDARD EQUIPMENT:</strong></p>
<ul><li>10" 3 JAW CHUCK </li><li>12" 4 JAW CHUCK</li><li> FACE PLATE</li><li>5-1/8" STEADY REST W/ ROLLER JAWS</li><li> 4-8/9" FOLLOW REST</li><li>GAP</li><li>4 WAY TOOL POST</li><li> THREADING CHASING DIAL</li><li>( 2 ) DEAD CENTERS</li><li> REDUCING SLEEVE</li><li>FULL LENGTH SPLASH GUARD</li><li> ONE PIECE CAST IRON BASE</li><li>FOOT BRAKE</li><li> HALOGEN WORK LIGHT</li><li>COOLANT SYSTEM</li><li> LEVELING PADS</li><li> 4 POSITION AUTO KICK-OUT LONGITUDINAL CARRIAGE TOOL BOX </li><li>TAPER TURN ATTACHMENT</li></ul>
