<p><b>SPECIFICATIONS:</b></p>
<table width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr>
<td bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: rgb(255, 255, 255);"><b>MODEL</b></span></div></td>
<td bgcolor="#333333" class="Title_white_bold"><div align="center"><span style="color: rgb(255, 255, 255);"><b>KGC-40120</b></span></div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Max.swing diameter over bed</div></td>
<td class="TableText"><div align="center">1030mm (40-1/2")</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Max.swing in gap</div></td>
<td valign="top" class="TableText"><div align="center">1200mm (47-1/4")</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Swing over cross slide</div></td>
<td class="TableText"><div align="center">700mm (27-1/2")</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Distance between centers</div></td>
<td width="257" class="TableText"><div align="center">3000mm (120")</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Length in gap from face plate</div></td>
<td class="TableText"><div align="center">380 (15")</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Spindle nose</div></td>
<td class="TableText"><div align="center">C11 or D11</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Spindle bore</div></td>
<td class="TableText"><div align="center">105mm (4-1/8") or 130mm (5-1/8")</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Taper of spindle bore</div></td>
<td class="TableText"><div align="center">Metric NO.120 or Metric NO.140</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Spindle speeds</div></td>
<td class="TableText"><div align="center">10-800rpm</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">No of spindle speeds</div></td>
<td class="TableText"><div align="center">18 steps</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Cross slide travel</div></td>
<td class="TableText"><div align="center">615mm (24-1/5")</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Top rest travel</div></td>
<td class="TableText"><div align="center">225mm (8-7/8")</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Rapid traverse</div></td>
<td class="TableText"><div align="center">Z :3200 (126"/min), X :1400 (55"/min)</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Quill diameter</div></td>
<td class="TableText"><div align="center">120mm (4-3/4")</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Quill travel</div></td>
<td class="TableText"><div align="center">270mm (10-5/8")</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Quill taper</div></td>
<td class="TableText"><div align="center">MT6</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Bed width</div></td>
<td class="TableText"><div align="center">610mm (24")</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Metric threads</div></td>
<td class="TableText"><div align="center">1-240mm, 53 kinds</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Inch threads</div></td>
<td class="TableText"><div align="center">30-2t pi, 31 kinds</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Modul threads</div></td>
<td class="TableText"><div align="center">0.25-60mm, 46 kinds</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Diametral pitch threads</div></td>
<td class="TableText"><div align="center">60-1/2 lpi, 47 kinds</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Longitudinal feed range</div></td>
<td class="TableText"><div align="center">0.07-16.72mm (0.00276"/rev.-0.658"/rev.)</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Cross feed range</div></td>
<td class="TableText"><div align="center">0.04-9.6mm (0.00157"/rev.-0.378"/rev.)</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Main motor power</div></td>
<td class="TableText"><div align="center">11kw (15 hp)</div></td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText"><div align="center">Packing size</div></td>
<td class="TableText"><div align="center">5310 x 1400 x 2000mm <br>(209" x 55" x 79")</div></td>
</tr>
<tr>
<td width="257" bgcolor="#cccccc" class="TableText"><div align="center">Gross weight/Net weight (Approx)</div></td>
<td class="TableText"><div align="center">6400/6900kg (14,110/15,212 lbs)</div></td>
</tr>
</tbody>
</table>
<p><b><br>FEATURES:</b></p>
<ul><li>KGC-40120 Lathe ( 40" x 120" ) , ( 5" / 130 mm Spindle Bore hole ) 3 PH, 220V /440V , 20 Horse Power + Taper Attachment installed</li></ul>
