<table width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div>Diameter of column
</div>
</td>
<td class="TableText" width="257">
<div>17"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Max distance from column to spindle
</div>
</td>
<td class="TableText">
<div>63"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Min distance from column to spindle
</div>
</td>
<td class="TableText">
<div>13.38"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Travel of spindle head
</div>
</td>
<td class="TableText">
<div>49.63"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Max distance from base to spindle end
</div>
</td>
<td class="TableText">
<div>63"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Min distance from base to spindle end
</div>
</td>
<td class="TableText">
<div>13"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Elevating height of arm
</div>
</td>
<td class="TableText">
<div>35.44"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Effective area of table
</div>
</td>
<td class="TableText">
<div>27-5/8" x 19-5/8" x 15-3/4"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Dimensions of base
</div>
</td>
<td class="TableText">
<div>97-5/8" x 41-11/32" x 8-1/4"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Drilling steel
</div>
</td>
<td class="TableText">
<div>2.25"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Drilling cast iron
</div>
</td>
<td class="TableText">
<div>2.625"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Tapping steel
</div>
</td>
<td class="TableText">
<div>2"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Tapping cast iron
</div>
</td>
<td class="TableText">
<div>2.375"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Boring steel
</div>
</td>
<td class="TableText">
<div>5"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Boring cast iron
</div>
</td>
<td class="TableText">
<div>7.375"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Taper hole sppindle
</div>
</td>
<td class="TableText">
<div>MT #5
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Stroke of spindle
</div>
</td>
<td class="TableText">
<div>14 - 9/16"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>R.P.M of spindle (rpm x steps)
</div>
</td>
<td class="TableText">
<div>40 - 1,920 rpm x 12 steps
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Feed of spindle (rev. x steps)
</div>
</td>
<td class="TableText">
<div>0.0028", 0.0378" x 6 steps
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Main motor
</div>
</td>
<td class="TableText">
<div>7.5 HP, 3 phase
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Elevating motor
</div>
</td>
<td class="TableText">
<div>2 HP
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Clamping motor for column and gear box
</div>
</td>
<td class="TableText">
<div>1 HP
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Coolant pump
</div>
</td>
<td class="TableText">
<div>1/8 HP
</div>
</td>
</tr>
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div>Max. machine height from floor
</div>
</td>
<td class="TableText">
<div>124-7/8"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Shipping Dimensions
</div>
</td>
<td class="TableText">
<div>112" x 53" x 117"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Net Weight
</div>
</td>
<td class="TableText">
<div>11,220 lbs.
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Shipping Weight
</div>
</td>
<td class="TableText">
<div>12,540 lbs
</div>
</td>
</tr>
</tbody>
</table>
<p>Design and Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul>
<li>Hydraulic clamping system of column, arm, and head independently controlled by push button switch. Vertical movement of arm is coordinated by an IC timer</li>
<li>Power elevating motor arm with anti-fall safety device</li>
<li>Cycling oil pump designed to cool off precision gears inside gearbox and minimize excessive wear and tear on gears to the lowest extent</li>
<li>Friction type disc clutch to absorb impact force caused by vertical movement of spindle and effectively protect all transmission units inside gearbox</li>
<li>Built-in clutch for quick spindle return to speed up tapping operation</li>
<li>Automatic tool ejector device to shift tools efficiently</li>
<li>Built-in work light</li>
<li>Built-in coolant system </li>
</ul>
<p><strong> STANDARD ACCESSORIES:</strong>
</p>
<ul>
<li>Plain box table</li>
<li>Work light</li>
<li>Coolant system</li>
</ul>
