<table width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr class="Title_white1" bgcolor="#333333">
<td class="TableText1" width="148">
<div class="Title_white_bold">
<div><strong><span style="color: rgb(255, 255, 255);">MODEL</span></strong>
</div>
</div>
</td>
<td class="Title_white_bold" width="90">
<div><span style="color: rgb(255, 255, 255);"><strong>AS625-6</strong></span>
</div>
</td>
<td class="Title_white_bold" width="90">
<div><span style="color: rgb(255, 255, 255);"><strong>AS625-8</strong></span>
</div>
</td>
<td class="Title_white_bold" width="90">
<div><span style="color: rgb(255, 255, 255);"><strong>AS625-10</strong></span>
</div>
</td>
<td class="Title_white_bold" width="90">
<div><span style="color: rgb(255, 255, 255);"><strong>AS625-12</strong></span>
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Cap. to Mild Steel (A36)
</div>
</td>
<td class="TableText1">
<div>5/8" x 6'
</div>
</td>
<td class="TableText1">
<div>5/8" x 8'
</div>
</td>
<td class="TableText1">
<div>5/8" x 10'
</div>
</td>
<td class="TableText1">
<div>5/8" x 12'
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Cap. to Stainless steel
</div>
</td>
<td class="TableText1">
<div>7/16" x 6'
</div>
</td>
<td class="TableText1">
<div>7/16" x 8'
</div>
</td>
<td class="TableText1">
<div>7/16" x 10'
</div>
</td>
<td class="TableText1">
<div>7/16" x 12'
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Shearing tons available
</div>
</td>
<td class="TableText1" colspan="4">
<div>130
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div># of hold down cylinders
</div>
</td>
<td class="TableText1">
<div>7
</div>
</td>
<td class="TableText1">
<div>9
</div>
</td>
<td class="TableText1">
<div>11
</div>
</td>
<td class="TableText1">
<div>13
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Bore of hold downs
</div>
</td>
<td class="TableText1" colspan="4">
<div>3"
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Hold down tons of force
</div>
</td>
<td class="TableText1">
<div>75
</div>
</td>
<td class="TableText1">
<div>90
</div>
</td>
<td class="TableText1">
<div>105
</div>
</td>
<td class="TableText1">
<div>125
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Weight (lbs.)
</div>
</td>
<td class="TableText1">
<div>28,000
</div>
</td>
<td class="TableText1">
<div>32,000
</div>
</td>
<td class="TableText1">
<div>36,000
</div>
</td>
<td class="TableText1">
<div>52,000
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Backgauge Travel
</div>
</td>
<td class="TableText1" colspan="4">
<div>48"
</div>
</td>
</tr>
</tbody>
</table>
<table width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr class="Title_white1" bgcolor="#333333">
<td class="TableText1" width="148">
<div class="Title_white_bold">
<div><strong><span style="color: rgb(255, 255, 255);">MODEL</span></strong>
</div>
</div>
</td>
<td class="Title_white_bold" width="121">
<div><span style="color: rgb(255, 255, 255);"><strong>AS625-14</strong></span>
</div>
</td>
<td class="Title_white_bold" width="120">
<div><span style="color: rgb(255, 255, 255);"><strong>AS625-16</strong></span>
</div>
</td>
<td class="Title_white_bold" width="121">
<div><span style="color: rgb(255, 255, 255);"><strong>AS625-20</strong></span>
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Cap. to Mild Steel (A36)
</div>
</td>
<td class="TableText1">
<div>5/8" x 14'
</div>
</td>
<td class="TableText1">
<div>5/8" x 16'
</div>
</td>
<td class="TableText1">
<div>5/8" x 20'
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Cap. to Stainless steel
</div>
</td>
<td class="TableText1">
<div>7/16" x 14'
</div>
</td>
<td class="TableText1">
<div>7/16" x 16'
</div>
</td>
<td class="TableText1">
<div>7/16" x 20'
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Shearing tons available
</div>
</td>
<td class="TableText1" colspan="3">
<div>130
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div># of hold down cylinders
</div>
</td>
<td class="TableText1">
<div>15
</div>
</td>
<td class="TableText1">
<div>17
</div>
</td>
<td class="TableText1">
<div>21
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Bore of hold downs
</div>
</td>
<td class="TableText1" colspan="3">
<div>3"
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Hold down tons of force
</div>
</td>
<td class="TableText1">
<div>140
</div>
</td>
<td class="TableText1">
<div>160
</div>
</td>
<td class="TableText1">
<div>180
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Weight (lbs.)
</div>
</td>
<td class="TableText1">
<div>66,000
</div>
</td>
<td class="TableText1">
<div>85,000
</div>
</td>
<td class="TableText1">
<div>125,000
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Backgauge Travel
</div>
</td>
<td class="TableText1" colspan="3">
<div>48"
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 5 YEAR</strong> – <strong>STANDARD </strong>Parts & Limited Onsite Labor
</p>
<ul>
<li><strong>Standard Industrial is 100% Owned, Operated and Manufactured In The U.S.A.</strong></li>
<li>Manual, side adjustable, quick-change blade gap adjustment</li>
<li>PLC controlled backgauge</li>
<li>A660 bronze bearings guaranteed for 5 years based on a 24 hour workday. These bearings easily last 15-20 years and the bronze material is always readily available.</li>
<li>Under 3,000 P.S.I. system pressure that provides substantially longer system life.</li>
<li>Extremely heavy-duty hold downs. Fewer hold downs = less maintenance. Hold down pressure is adjustable for your sensitive material.</li>
<li>Extremely heavy duty, precision tables designed to provide the least amount of deflection and to last generations</li>
<li>Incredibly strong gusseted table providing decades of reliable performance</li>
<li>Complete O.S.H.A. and ANSI B11.4 Compliance</li>
<li>Positive mechanical tapered gibbs for smooth uniform gap adjustment</li>
<li>Easy to understand mechanical gap indicators showing exact gap placement and infinite adjustment</li>
<li>Incredibly simple, easy to troubleshoot hydraulic system is fully covered by our 5 year warranty and is comprised of all readily available components</li>
<li>Lifetime Parts Availability: Every component on machine is available from your local suppliers giving you a lifetime of productivity and parts</li>
<li>Shadow light for precise shearing line</li>
</ul>
<p><strong>STANDARD EQUIPMENT:</strong>
</p>
<ul>
<ul>
<li>PLC Touch Screen Control</li>
<li>36” or 48” Travel EXTREMELY Heavy Duty Backgauge</li>
<li>Fully Loaded, Extremely Heavy Duty Table</li><li>All 1/4” and 3/8” shears that are 12’ and shorter come standard with a manual side adjustable gap adjustment.</li></ul></ul><div><b>OPTIONAL ITEMS:
</b></div><ul><ul>
</ul>
</ul><ul><li>Optional AUTOMEC CNC Control </li><li>Squaring Arms</li><li>Swing Stops For Squaring Arms</li><li>Disappearing/Gravity Stops for T-Slots</li><li>Support Arms</li><li>T-Slot Across Front Edge of Table</li><li>Ball Transfers in Table</li><li>Additional T-Slots in Table</li><li>Additional Hand Slots in Table</li><li>Protractor</li><li>Full Nylatron Table Cover</li><li>48” travel in lieu of 36”</li><li>Automatic Power Swing-Away Backgauge</li><li>High Speed Hydraulic System</li><li>Impact Pads for Hold Down Cylinders</li><li>Additional Hold Downs</li><li>Independent Activation of Hold Downs</li><li>Automatic Lubrication System</li><li>2 Position Power Rake Adjustment</li><li>Infinitely Variable Power Blade Gap Adjustment</li><li>Paint Color</li><li>Shear Blades</li><li>Oil Cooler</li><li>Conveyors</li><li>Stacker</li><li>Pneumatic Sheet Supports</li><li>Onsite Training</li><li>Light Curtain Safety Barriers</li><li>Physical Barriers/Cages</li><li>Compliance Options</li><li>CNC Square Gauge Systems</li><li>*Other lengths of Shears and Special Process/Cut To Length Line Shears Are Available Per Special Quote</li></ul>
