<table width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr>
<td class="Title_white_bold" rowspan="9" width="128" bgcolor="#333333">
<div>
<div><span style="color: #ffffff;"><strong>SPINDLE CAPACITY</strong></span>
</div>
</div>
</td>
<td class="TableText" bgcolor="#cccccc">
<div>With jaw chucks
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>6"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>With expanding collets
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>3"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>With round 5C collets
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>1-1/16"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>With hexagon 5C collets
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>7/8"
</div>
</td>
</tr>
<tr>
<td class="TableText" width="192" bgcolor="#cccccc">
<div>With square 5C collets
</div>
</td>
<td class="TableText" width="192" bgcolor="#ffffff">
<div>3/4"
</div>
</td>
</tr>
<tr>
<td class="TableText" width="192" bgcolor="#cccccc">
<div>With step chucks
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>1-1/16” to 6”
</div>
</td>
</tr>
<tr>
<td class="TableText" width="192" bgcolor="#cccccc">
<div>Spindle nose diameter
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>2-3/16”
</div>
</td>
</tr>
<tr>
<td class="TableText" width="192" bgcolor="#cccccc">
<div>Spindle nose I.D. / O.D.
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>5C / 4º taper
</div>
</td>
</tr>
<tr>
<td class="TableText" width="192" bgcolor="#cccccc">
<div>Variable spindle speeds
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>0 ~ 4,000 rpm (5C Collet)
</div>
</td>
</tr>
<tr>
<td class="Title_white_bold" bgcolor="#333333">
<div>
<div><span style="color: #ffffff;"><strong>CAPACITY</strong></span>
</div>
</div>
</td>
<td class="TableText" width="192" bgcolor="#cccccc">
<div>Swing over bed
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>9"
</div>
</td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="2" bgcolor="#333333">
<div>
<div><span style="color: #ffffff;"><strong>POWER</strong></span>
</div>
</div>
</td>
<td class="TableText" bgcolor="#cccccc">
<div>Inverter spindle motor
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>1 HP, 220V, 3PH
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Coolant pump
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>Optional
</div>
</td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="2" bgcolor="#333333">
<div>
<div><span style="color: #ffffff;"><strong>WEIGHT & DIMENSIONS</strong></span>
</div>
</div>
</td>
<td class="TableText" width="192" bgcolor="#cccccc">
<div>
<div>Machine dimensions (LxWxH):
</div>
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>36” x 36” x 55”
</div>
</td>
</tr>
<tr>
<td class="TableText" width="192" bgcolor="#cccccc">
<div>
<div>Gross weight:
</div>
</div>
</td>
<td class="TableText" bgcolor="#ffffff">
<div>
<div>820 lbs.
</div>
</div>
</td>
</tr>
</tbody>
</table>
<p>Design and Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul>
<li>Easy to read digital display on actual spindle rpm</li>
<li>Welded steel pedestal</li>
<li>High accuracy spindle</li>
<li>Hardened and ground</li>
<li>Precision steel bedways</li>
<li>Compact design</li>
<li>Fast setup</li>
<li>Easy operation</li>
<li>Fast lever collet chucking</li>
<li>Wide chip pan</li>
<li>Foot rest</li>
<li>5C lever type collet closer standard</li>
<li>1 HP frequency controlled motor</li>
</ul>
<p><strong> STANDARD ACCESSORIES:</strong>
</p>
<ul>
<li>Variable frequency drive</li>
<li>5C lever type collet closer</li>
<li>Double tool cross slide</li>
<li>Welded steel pedestal</li>
<li>Manual and parts list</li>
</ul>
<p><b>OPTIONAL ITEMS - CALL FOR PRICE:</b></p>
<ul>
<li>Compound slide</li>
<li>5C collet fixture plate</li>
<li>Vertical cut-off slide without cut-off blade</li>
<li>Step chuck and closer</li>
<li>5C collet set</li>
<li>Fixture plate</li>
<li>Expanding collet and pads</li>
<li>Straight and taper turning slide for double tool cross slide </li>
<li>Thread positive stops</li>
<li>Tool holder collet (collet type)</li>
<li>Releasing tap holder (collet type)</li>
</ul>
