<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr>
<td width="114" rowspan="4" bgcolor="#cccccc" class="TableText">
<div align="center">Roll Capacity
</div>
</td>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Mild Steel
</div>
</td>
<td nowrap="nowrap" class="TableText">
<div align="center">5 ft 1 in. ft x 10 ga.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Stainless Steel
</div>
</td>
<td nowrap="nowrap" class="TableText">
<div align="center">5 ft 1 in. ft x 12 ga.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Soft Aluminum
</div>
</td>
<td nowrap="nowrap" class="TableText">
<div align="center">5 ft 1 in. ft x 1/4 in.
</div>
</td>
</tr>
<tr>
<td width="141" bgcolor="#cccccc" class="TableText">
<div align="center">Min. Thickness
</div>
</td>
<td width="257" nowrap="nowrap" class="TableText">
<div align="center">26 ga.
</div>
</td>
</tr>
<tr>
<td colspan="2" bgcolor="#cccccc" class="TableText">
<div align="center">Roll Dia.
</div>
</td>
<td nowrap="nowrap" class="TableText">
<div align="center">4-3/4 in.
</div>
</td>
</tr>
<tr>
<td colspan="2" bgcolor="#cccccc" class="TableText">
<div align="center">Min. Bending Dia. Inch
</div>
</td>
<td nowrap="nowrap" class="TableText">
<div align="center">6 in.
</div>
</td>
</tr>
<tr>
<td colspan="2" bgcolor="#cccccc" class="TableText">
<div align="center">Pre-bend inch
</div>
</td>
<td nowrap="nowrap" class="TableText">
<div align="center">0.12 in.
</div>
</td>
</tr>
<tr>
<td colspan="2" bgcolor="#cccccc" class="TableText">
<div align="center">Rolls Speed ft/min
</div>
</td>
<td nowrap="nowrap" class="TableText">
<div align="center">20
</div>
</td>
</tr>
<tr>
<td colspan="2" bgcolor="#cccccc" class="TableText">
<div align="center">Rolls Opening
</div>
</td>
<td nowrap="nowrap" class="TableText">
<div align="center">1/2 in.
</div>
</td>
</tr>
<tr>
<td colspan="2" bgcolor="#cccccc" class="TableText">
<div align="center">Main Motor
</div>
</td>
<td nowrap="nowrap" class="TableText">
<div align="center">3 HP, 3PH, 220V or 440V
</div>
</td>
</tr>
<tr>
<td colspan="2" bgcolor="#cccccc" class="TableText">
<div align="center">Weight
</div>
</td>
<td nowrap="nowrap" class="TableText">
<div align="center">3,050 lbs.
</div>
</td>
</tr>
<tr>
<td colspan="2" bgcolor="#cccccc" class="TableText">
<div align="center">Overall Dimensions
</div>
</td>
<td nowrap="nowrap" class="TableText">
<div align="center">96 x 32 x 52 in.
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul class="TableText">
<li>This machine has a 3HP Motor, rated at 220V three phase. Power bending roll up/down with push button & display.</li>
<li>SO 9001 certified</li>
<li>Taiwan machines</li>
<li>All (3) rolls are hardened rolls, up to 50-52 HRC</li>
<li>3-rollers are driven to perform high accuracy</li>
<li>Adjustable cone attachment included</li>
<li>3/8”, ½” and 5/8” grooves on rollers</li>
<li>One wheel one-side operated for bending roll</li>
<li>One wheel one-site operated for pinch roll (E model is powered)</li>
<li>Heavy duty casting frame</li>
<li>Heavy duty all steel welded construction</li>
<li>1/3 of full length in middle of roller is straight, and two ends with crown to get perfect round performance.</li>
<li>Quiet running operation</li>
<li>Easy swing-out top roller</li>
<li>Safety line all around the machine for emergency stop</li>
<li>All rolls run forward and reverse</li>
<li>Safety type forward/reverse foot pedal</li>
<li>Power source 220V, (option: 440V, 3 phase)</li>
<li>One year industrial warranty for parts</li>
</ul>
<p><strong> STANDARD EQUIPMENT: </strong>
</p>
<ul>
<li>Adjustable cone attachment</li>
<li>3/8", ½" and 5/8" grooves on rollers</li>
<li>All (3) hardened rolls</li>
<li>Removable safety foot pedal</li>
<li>Operation & parts manual</li>
<li>Orange color front cover is optional.</li>
<li>E models come with motorized bending roll up/down w/ push button and digital display for easy operation of repeat jobs</li>
</ul>
<p><b>OPTIONAL ITEMS - CALL FOR PRICE:</b></p>
<ul>
<li>Safety fence for enclosure of the back side of the machine</li>
</ul>
