<table width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div>Diameter of column
</div>
</td>
<td class="TableText" width="257">
<div>10.25"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Max distance from column to spindle
</div>
</td>
<td class="TableText">
<div>43.31"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Min distance from column to spindle
</div>
</td>
<td class="TableText">
<div>9.625"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Travel of spindle head
</div>
</td>
<td class="TableText">
<div>33.625"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Max distance from base to spindle end
</div>
</td>
<td class="TableText">
<div>50.375"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Min distance from base to spindle end
</div>
</td>
<td class="TableText">
<div>12.625"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Elevating height of arm
</div>
</td>
<td class="TableText">
<div>24"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Effective area of table
</div>
</td>
<td class="TableText">
<div>24-3/4” x 20-1/2” x 16-1/2"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Dimensions of base
</div>
</td>
<td class="TableText">
<div>67-3/4” x 28” x 6-1/2"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Drilling steel
</div>
</td>
<td class="TableText">
<div>1.56"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Drilling cast iron
</div>
</td>
<td class="TableText">
<div>2.19"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Tapping steel
</div>
</td>
<td class="TableText">
<div>0.75"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Tapping cast iron
</div>
</td>
<td class="TableText">
<div>0.75"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Boring steel
</div>
</td>
<td class="TableText">
<div>3.38"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Boring cast iron
</div>
</td>
<td class="TableText">
<div>4.75"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Taper hole sppindle
</div>
</td>
<td class="TableText">
<div>M.T. #4
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Stroke of spindle
</div>
</td>
<td class="TableText">
<div>9"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Spindle speeds (rpm x steps)
</div>
</td>
<td class="TableText">
<div>44 ~ 1,500 rpm x 12 steps <br>(44, 77, 88, 147, 154, 228, 282, 398, 456, 750, 796, 1500)
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Spindle feeds (rev. x steps)
</div>
</td>
<td class="TableText">
<div>0.002”, 0.0035”, 0.0059” x 3 steps
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Main motor
</div>
</td>
<td class="TableText">
<div>3 HP, 3 phase (2-speed motor)
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Elevating motor
</div>
</td>
<td class="TableText">
<div>1 HP
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Coolant pump
</div>
</td>
<td class="TableText">
<div>1/8 HP
</div>
</td>
</tr>
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div>Machine height from floor
</div>
</td>
<td class="TableText">
<div>100"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Shipping Dimensions
</div>
</td>
<td class="TableText">
<div>74" x 34" x 89"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Net Weight
</div>
</td>
<td class="TableText">
<div>3,960 lbs.
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Shipping Weight
</div>
</td>
<td class="TableText">
<div>4,290 lbs
</div>
</td>
</tr>
</tbody>
</table>
<p>Design and Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul>
<li>Power elevating motor arm with anti-fall safety device </li>
<li>Spindle is balanced by means of cylinder shap spring </li>
<li>Hardened and precision ground arm ways </li>
<li>High speed gears are made of Nickel-Chrome steel and through heat treatment process and precision grinding </li>
<li>Manual clamping of column, arm, and head </li>
<li>Limit safety device for operation </li>
<li>Built-in work light </li>
<li>Built-in coolant system </li>
</ul>
<p><strong>EQUIPPED WITH:</strong>
</p>
<ul>
<li>Plain box table </li>
<li>Work light</li>
<li>Coolant system</li>
</ul>
