COLE-TUVE HPK-120 5 x 5 x 1/2 in. Hydraulic Double-Pinch Angle Bending Roll

COLE-TUVE HPK-120 5 x 5 x 1/2 in. Hydraulic Double-Pinch Angle Bending Roll

Have one to sell?
386-304-3720
dan@sierravictor.com
ConditionNew
Have one to sell?

Overview

Type:
Roll Benders
Manufacturer:
COLE TUVE
Model:
HPK-120
Condition:
Build To Order
Stock #:
HPK-120
Status:
For Sale

Description

All Three Rolls are Powered by Hydro-Motors and Planetary Gearboxes. Standard Rolls Handle Many Shapes. Two Electronic Digital Readouts (LED). Horizontal and Vertical Working Positions.

Angle Roll TypeHydraulicHydraulic
Roll Diameter Ø15.35"0.4 m
Shaft Ø4.72"119.89 mm
Motor Power20 HP20 HP
Driven Rolls33
Rolling Speed, FPM6-1/2 & 24-1/26-1/2 & 24-1/2
Roll AdjustmentHydraulicHydraulic
Pipe Capacity5" Sch. 40, ø60"5" Sch. 40, ø60"
Round Tube Capacity(SP) 5-1/2" x 1/8", ø59"(SP) 5-1/2" x 1/8", ø59"
Square Tube Capacity3-1/2" x 3-1/2" x 3/16", ø71"3-1/2" x 3-1/2" x 3/16", ø71"
Rectangular Tube Capacity4-3/4" x 1-1/2" x 5/32", ø71"4-3/4" x 1-1/2" x 5/32", ø71"
Square Bar2-1/2", ø30"2-1/2", ø30"
Round Bar(SP) 3-1/8", ø34"(SP) 3-1/8", ø34"
Flat Bar Easy Way8" x 2", ø40"8" x 2", ø40"
Flat Bar Hard Way5" x 1", ø48"5" x 1", ø48"
Angle Iron Leg-In4" x 4" x 3/8", ø48"4" x 4" x 3/8", ø48"
Angle Iron Let-Out5" x 5" x 1/2", ø60"5" x 5" x 1/2", ø60"
T-Iron Leg-In4" x 7/16", ø40"4" x 7/16", ø40"
T-Iron Leg-Out4" x 7/16", ø32"4" x 7/16", ø32"
Channel Leg-In7", ø36"7", ø36"
Channel Leg-Out7", ø32"7", ø32"
Upper Roll Dia.15.35"389.89 mm
Lower Roll Dia.15.35"389.89 mm
StyleDouble PinchDouble Pinch
Working PlaneHorizontal/VerticalHorizontal/Vertical
Digital ReadoutYesYes
Dimensions79 x 65 x 75 in.79 x 65 x 75 in.
Weight10,494 lbs.10,494 lbs.

*The shapes marked (SP) require optional special rolls. The other shapes can normally be rolled with the stardard rolls supplied with the machine. For production runs of some of those shapes, optional special rolls may be desirable. Rolling angle leg-in requires optional leg-in guide rolls and may require special rolls.

Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts

Optional Items - Call for price:
*Pipe/Tube/Shape Bending Rolls
*Beam-On-Edge Bending Device
*NC Control
