<table width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr class="Title_white" bgcolor="#333333">
<td class="TableText">
<div class="Title_white_bold"><strong><span style="color: rgb(255, 255, 255);">MODEL</span></strong>
</div>
</td>
<td class="TableText">
<div class="Title_white_bold"><span style="color: rgb(255, 255, 255);"><strong>H-0445</strong></span>
</div>
</td>
</tr>
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div>Cutting Capacity
</div>
</td>
<td class="TableText" width="257" valign="middle">
<div>
<div>4'
</div>
</div>
</td>
</tr>
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div>Mild Steel
</div>
</td>
<td class="TableText" valign="middle">
<div>7 GA
</div>
</td>
</tr>
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div>Stainless Steel
</div>
</td>
<td class="TableText" valign="middle">
<div>11 GA
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Blade Length
</div>
</td>
<td class="TableText" valign="middle">
<div>4' 4"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Strokes Per Minute (S.P.M.)
</div>
</td>
<td class="TableText" width="257" valign="middle">
<div>40 - 55
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Hold-Downs Number
</div>
</td>
<td class="TableText" width="257" valign="middle">
<div>
<div>8
</div>
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Hold-Downs Pressure (Tons)
</div>
</td>
<td class="TableText" width="257" valign="middle">
<div>
<div>3.2
</div>
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Front Support (Inch)
</div>
</td>
<td class="TableText" valign="middle">
<div>40
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Back Gauge (Inch)
</div>
</td>
<td class="TableText" valign="middle">
<div>24
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Top Blade Rake Adjustment
</div>
</td>
<td class="TableText" valign="middle">
<div>Hydraulic Adjustment Rake Angle &<br> Blade Clearance Adjust
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Top Blade Rake Angle
</div>
</td>
<td class="TableText" valign="middle">
<div>1/2 - 2°
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Motor (HP)
</div>
</td>
<td class="TableText" valign="middle">
<div>10
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Oil Tank Capacity (Gal)
</div>
</td>
<td class="TableText" valign="middle">
<div>25
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Dimensions approx.
</div>
</td>
<td class="TableText" valign="middle">
<div>91" x 48" x 63"
</div>
</td>
</tr>
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div>Net Weight (lbs)
</div>
</td>
<td class="TableText" valign="middle">
<div>4,800
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul>
<li><strong>MADE IN TAIWAN</strong></li>
<li>Well balanced and sturdy welded machine frame provides constant stability and rigidity</li>
<li> The centralized hydraulic logical system offers the best performance with a quiet hydraulic pump</li>
<li>Independent hydraulic pressure hold-downs synchronized with upper blade, ensuring the work piece is securely clamped at the moment of cutting</li>
<li> High grade carbon/chrome alloy steel blades ensure maximum accuracy cutting and longer blade life, 60hrc hardened</li>
<li> Blade clearance (gap) setting can be easily and quickly done by adjusting handle. (Standard for H-0445 and heavier models)</li>
<li> Hydraulic adjustable rake angle design is a standard feature for all models, this allows the operator to obtain best rake angle for each application and minimize possible bowing and twisting</li>
<li> Adjustable cutting length and stroke</li>
<li> Shadow line lighting covering full length of worktable, this is very helpful to operator for positioning and shearing work piece</li>
<li> Worktable mounted with ball transfer type plates, for easier loading and moving work piece</li>
<li> Full-length and full view safety finger guard, to protect operator from cutting hazard</li>
<li> Removable foot remote pedal is fitted with safety protection, the upper blade beam will rise to top position immediately, when the operator removes off his foot from the pedal</li>
<li> All motors and pumps are overload protected</li>
<li> Jog, single, or continuous cutting modes</li>
</ul>
<p><strong>STANDARD ACCESSORIES:</strong>
</p>
<ul>
<li>Blades</li>
<li>24" Manual Back Gauge</li>
<li>40" Front Support Arm</li>
<li>40" Squaring Arm</li>
<li>Finder Guard</li>
<li>Foot Pedal</li>
<li>Shadow Line Lighting</li>
</ul>
<p><strong> EQUIPPED WITH:</strong>
</p>
<ul>
<li>High grade, high carbon/chrome 2-edge upper blade, and 4-edge bottom blade, 60hrc. </li>
<li> Hydraulic rake angle adjustment. </li>
<li> Two 40” front support arms with front setters</li>
<li> One 40” squaring arm with dual scale</li>
<li> 24” manual back gauge with dual scales and crank wheel</li>
<li>Full length finger guard and shadow line lighting</li>
<li> Hydraulic independent hold-downs</li>
<li>Overload protected hydraulic system</li>
<li> Removable foot control pedal with safety protection</li>
<li> Full electrics & cabinet with operation panel</li>
<li> Tool box and leveling pads. </li>
</ul>
