<table width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr>
<td class="Title_white_bold" bgcolor="#333333">
<div><span style="color: #ffffff;"><strong>MODEL</strong></span>
</div>
</td>
<td class="Title_white_bold" width="257" bgcolor="#333333">
<div><span style="color: #ffffff;"><strong>833</strong></span>
</div>
</td>
</tr>
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div>Diameter of column
</div>
</td>
<td class="TableText">
<div>8.25"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Max distance from column to spindle
</div>
</td>
<td class="TableText">
<div>33.50"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Min distance from column to spindle
</div>
</td>
<td class="TableText">
<div>8.625"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Travel of spindle head
</div>
</td>
<td class="TableText">
<div>24.875"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Max distance from base to spindle end
</div>
</td>
<td class="TableText">
<div>47.625"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Min distance from base to spindle end
</div>
</td>
<td class="TableText">
<div>13.75"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Elevating height of arm
</div>
</td>
<td class="TableText">
<div>25.56"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Effective area of table
</div>
</td>
<td class="TableText">
<div>23-7/16” x 17-23/32” x 14-31/32"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Dimensions of base
</div>
</td>
<td class="TableText">
<div>49-5/8” x 25-3/16” x 6-9/32"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Drilling capacity steel
</div>
</td>
<td class="TableText">
<div>1.25"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Drilling capacity cast iron
</div>
</td>
<td class="TableText">
<div>1.97"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Tapping steel
</div>
</td>
<td class="TableText">
<div>0.875"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Tapping cast iron
</div>
</td>
<td class="TableText">
<div>0.875"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Boring capacity (steel):
</div>
</td>
<td class="TableText">
<div>2.75"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Boring capacity (cast iron):
</div>
</td>
<td class="TableText">
<div>4.17"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Taper hole sppindle
</div>
</td>
<td class="TableText">
<div>MT #4
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Stroke of spindle
</div>
</td>
<td class="TableText">
<div>8.25"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Spindle speeds (rpm x steps)
</div>
</td>
<td class="TableText">
<div>88, 154, 282, 455, 796, 1500 x 6 steps
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Spindle feeds (rev. x steps)
</div>
</td>
<td class="TableText">
<div>0.002”, 0.0035”, 0.0059” x 3 steps
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Main motor
</div>
</td>
<td class="TableText">
<div>2 HP, 3 phase
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Elevating motor
</div>
</td>
<td class="TableText">
<div>1 HP
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Clamping motor
</div>
</td>
<td class="TableText">
<div>—
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Coolant pump
</div>
</td>
<td class="TableText">
<div>1/8 HP
</div>
</td>
</tr>
<tr>
<td class="TableText" width="257" bgcolor="#cccccc">
<div>Machine height from floor
</div>
</td>
<td class="TableText">
<div>91-3/8"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Shipping Dimensions
</div>
</td>
<td class="TableText">
<div>66" x 32" x 86"
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Net Weight
</div>
</td>
<td class="TableText">
<div>2,750 lbs.
</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#cccccc">
<div>Shipping Weight
</div>
</td>
<td class="TableText">
<div>3,080 lbs.
</div>
</td>
</tr>
</tbody>
</table>
<p>Design and Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul>
<li>Power elevating motor arm with an anti-fall safety device</li>
<li>Hardened and precision ground arm ways</li>
<li>High speed gears are made of Nickel-Chrome steel and through the heat treatment process and precision grinding</li>
<li>Extra auxiliary dial for spindle feed depth indication to review the momental feed depth of spindle</li>
<li>Special mechanism for spindle balance to avoid the defect on breaking of balance spring</li>
<li>Manual clamping of column, arm, and head</li>
<li>Built-in work light</li>
<li>Built-in coolant system</li>
</ul>
<p><strong> STANDARD ACCESSORIES: </strong>
</p>
<ul>
<li>Plain box table</li>
<li>Work light</li>
<li>Coolant system</li>
</ul>
