<table cellspacing="0" cellpadding="0" border="1" width="520" class="TableText">
<tbody style="text-align: center;">
<tr>
<td width="74" rowspan="4" bgcolor="#cccccc">
<div align="center">Capacity
</div>
</td>
<td width="82" rowspan="2" bgcolor="#cccccc">
<div align="center">90°
</div>
</td>
<td width="96" bgcolor="#cccccc">
<div align="center">Rectangular
</div>
</td>
<td width="258">
<div align="center">25” High x 40” Wide
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Round
</div>
</td>
<td width="258">
<div align="center">25.5"
</div>
</td>
</tr>
<tr>
<td rowspan="2" bgcolor="#cccccc">
<div align="center">45°
</div>
</td>
<td width="96" bgcolor="#cccccc">
<div align="center">Rectangular
</div>
</td>
<td width="258">
<div align="center">25” High x 24” Wide
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">Round
</div>
</td>
<td width="258">
<div align="center">—
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Weight Capacity
</div>
</td>
<td>
<div align="center">15,000 lbs
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Blade Speed
</div>
</td>
<td>
<div align="center">60-500 SFPM
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Blade Size
</div>
</td>
<td>
<div align="center">2” x .063” x 26’-6”
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Blade Guide
</div>
</td>
<td>
<div align="center"><span id="ctl00_ContentPlaceHolder1_lblContent2">Spring Loaded Carbide</span>
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Blade Tension
</div>
</td>
<td>
<div align="center">Hydraulic
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Bandwheel Size
</div>
</td>
<td>
<div align="center">26"
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Vise
</div>
</td>
<td>
<div align="center">Hydraulic
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Blade Drive
</div>
</td>
<td>
<div align="center">15 HP, AC Vector Drive
</div>
</td>
</tr>
<tr>
<td rowspan="4" bgcolor="#cccccc">
<div align="center">Voltage
</div>
</td>
<td rowspan="4" bgcolor="#cccccc">
<div align="center">Order Number
</div>
</td>
<td bgcolor="#cccccc">
<div align="center">0010706
</div>
</td>
<td>
<div align="center">208-60-3
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">0010707
</div>
</td>
<td>
<div align="center">230-60-3
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">0010708
</div>
</td>
<td>
<div align="center">460-60-3
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc">
<div align="center">0010709
</div>
</td>
<td>
<div align="center">575-60-3
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Sawing Force
</div>
</td>
<td>
<div align="center">0-1,000 lbs
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Coolant Capacity
</div>
</td>
<td>
<div align="center">15 Gallons
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Hydraulic Capacity
</div>
</td>
<td>
<div align="center">20 Gallons
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Hydraulic Drive
</div>
</td>
<td>
<div align="center">5 HP Motor
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Work Height
</div>
</td>
<td>
<div align="center">28"
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Outfeed Table
</div>
</td>
<td>
<div align="center">24” x 40”
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Vise Jaw Height
</div>
</td>
<td>
<div align="center">17"
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Shipping Weight
</div>
</td>
<td>
<div align="center">7,000 lbs
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Electrics
</div>
</td>
<td>
<div align="center">Wired to NFPA 79 Machine Tool Standards
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Machine Dimensions
</div>
</td>
<td>
<div align="center">170” Length x 55" Width x 100" Height
</div>
</td>
</tr>
<tr>
<td colspan="3" bgcolor="#cccccc">
<div align="center">Ship Dimensions
</div>
</td>
<td>
<div align="center">55” L x 156” W x 98” H
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul>
<li><strong>MADE IN USA</strong></li>
<li>2” Bi-Metal Blade</li>
<li>AC Vector Drive</li>
<li>Spring Loaded Carbide Guides</li>
<li>Hydraulic Vise Operation</li>
<li>Hydraulic Blade Tension</li>
<li>Semi-Automatic Operation</li>
<li>Built-In Coolant System</li>
<li>45° Swiveling Vise</li>
<li>Hydraulic Powered Blade Brush</li>
<li>TEFC Motors</li>
<li>Fused Disconnect with Lock-Out</li>
<li>Blade Break/Stall Switch</li>
<li>Console Controlled Blade Speed</li>
<li>Feed Pressure Monitor/Regulator</li>
<li>Low Voltage/Overload Protection</li>
<li>Electronic Door Safety Interlocks</li>
<li>Work Lights</li>
<li>Hydraulic Positioned Guide Arm</li>
<li>All Safety Guards</li>
<li>Operator Manual and Parts List</li>
<li>Blade Tension Indicator</li>
<li><span id="ctl00_ContentPlaceHolder1_lblContent">Blade Break/Stall Switch</span></li>
</ul>
<p><b>OPTIONAL ITEMS - CALL FOR PRICE:</b></p>
<table class="TableText" width="520" cellspacing="0" cellpadding="0" border="1">
<tbody style="text-align: center;">
<tr class="Title_white" bgcolor="#333333">
<td class="optional_accessories" width="77">
<div class="Title_white_bold" align="center"><span style="color: rgb(255, 255, 255);"><strong>PART #</strong></span>
</div>
</td>
<td width="361" bgcolor="#333333"><span style="color: rgb(255, 255, 255);"><strong></strong></span>
<div class="Title_white_bold" align="center"><span style="color: rgb(255, 255, 255);"><strong>ITEM</strong></span>
</div>
</td>
</tr>
<tr>
<td class="optional_accessories" bgcolor="#CCCCCC">
<div align="center">0056073
</div>
</td>
<td>
<div align="center">Discharge Worktable 40" Wide x 56" Long
</div>
</td>
</tr>
<tr>
<td class="optional_accessories" bgcolor="#CCCCCC">
<div align="center">0056081
</div>
</td>
<td>
<div align="center">Hydraulic Chip Conveyor, Auger Style
</div>
</td>
</tr>
<tr>
<td class="optional_accessories" bgcolor="#CCCCCC">
<div align="center">0056064
</div>
</td>
<td>
<div align="center">Hydraulic Holddown, Saw Vise
</div>
</td>
</tr>
<tr>
<td class="optional_accessories" bgcolor="#CCCCCC">
<div align="center">0056075
</div>
</td>
<td>
<div align="center">Outboard Vise with Hydraulic Holddown
</div>
</td>
</tr>
<tr>
<td class="optional_accessories" bgcolor="#CCCCCC">
<div align="center">0056074
</div>
</td>
<td>
<div align="center">Outboard Vise
</div>
</td>
</tr>
<tr>
<td class="optional_accessories" bgcolor="#CCCCCC">
<div align="center">—
</div>
</td>
<td>
<div align="center">Free Standing Control Console
</div>
</td>
</tr>
<tr>
<td class="optional_accessories" bgcolor="#CCCCCC">
<div align="center">—
</div>
</td>
<td>
<div align="center">High Speed Drive & Guides (1-1/2” Blade) 500-3000 SFPM
</div>
</td>
</tr>
<tr>
<td class="optional_accessories" bgcolor="#CCCCCC">
<div align="center">0056200
</div>
</td>
<td>
<div align="center">Hydraulic Powered Conveyor 40" x 10'
</div>
</td>
</tr>
<tr>
<td class="optional_accessories" bgcolor="#CCCCCC">
<div align="center">0056198
</div>
</td>
<td>
<div align="center">Non-Powered Conveyor 40" x 5'
</div>
</td>
</tr>
<tr>
<td class="optional_accessories" bgcolor="#CCCCCC">
<div align="center">0056199
</div>
</td>
<td>
<div align="center">Non-Powered Conveyor 40" x 10'
</div>
</td>
</tr>
<tr>
<td class="optional_accessories" bgcolor="#CCCCCC">
<div align="center">—
</div>
</td>
<td>
<div align="center">B-25-3 with Automatic Barfeed see B-25-3A3 CNC
</div>
</td>
</tr>
</tbody>
</table>
