<p><b>SPECIFICATIONS:</b></p>
<table border="1" cellspacing="0" cellpadding="0" width="520">
<tbody style="text-align: center;">
<tr>
<td class="Title_white_bold" rowspan="6" width="104" bgcolor="#333333">
<div><span style="color: #ffffff;"><strong> </strong><strong>CAPACITY</strong></span></div>
</td>
<td class="TableText" width="209" bgcolor="#CCCCCC">
<div>Max. swing over bed</div>
</td>
<td class="TableText" width="199">
<div>16-1/8"</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Max. length of workpiece</div>
</td>
<td class="TableText">
<div>40"</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Max. swing over carriage</div>
</td>
<td class="TableText">
<div>8-13/16"</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Max. swing in gap</div>
</td>
<td class="TableText">
<div>25-3/16"</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Effective length in gap</div>
</td>
<td class="TableText">
<div>9-1/2"</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Width of bed</div>
</td>
<td class="TableText">
<div>11-13/16"</div>
</td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="4" bgcolor="#333333">
<div><span style="color: #ffffff;"><strong>HEADSTOCK</strong></span></div>
</td>
<td class="TableText" bgcolor="#CCCCCC">
<div>Spindle nose</div>
</td>
<td class="TableText" valign="top">
<div>D1-6</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Diameter of spindle thru bore</div>
</td>
<td class="TableText">
<div>2-9/32"</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Taper of spindle center</div>
</td>
<td class="TableText">
<div>MT #6 (sleeve #6 / #4)</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Spindle speeds</div>
</td>
<td class="TableText">
<div>25 - 2000 rpm, 12 steps</div>
</td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="6" bgcolor="#333333">
<div><span style="color: #ffffff;"><strong>FEEDS & THREADS</strong></span></div>
</td>
<td class="TableText" bgcolor="#CCCCCC">
<div>Longitudinal feeds</div>
</td>
<td class="TableText">
<div>.0011" - .0633" / rev., 42 kinds</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Cross feeds</div>
</td>
<td class="TableText">
<div>.00033" - .01837" / rev., 42 kinds</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Metric threads</div>
</td>
<td class="TableText">
<div>0.1 - 14mm, 41 kinds</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Inch threads</div>
</td>
<td class="TableText">
<div>112 - 2 TPI, 60 kinds</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Module threads</div>
</td>
<td class="TableText">
<div>0.1 - 7mm, 34 kinds</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Diametral pitch threads</div>
</td>
<td class="TableText">
<div>112 - 4 DP, 50 kinds</div>
</td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="2" bgcolor="#333333">
<div><span style="color: #ffffff;"><strong>CARRIAGE</strong></span></div>
</td>
<td class="TableText" bgcolor="#CCCCCC">
<div>Max. travel of cross slide</div>
</td>
<td class="TableText">
<div>12-3/16"</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Max. travel of top slide</div>
</td>
<td class="TableText">
<div>5"</div>
</td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="3" bgcolor="#333333">
<div><span style="color: #ffffff;"><strong>TAILSTOCK</strong></span></div>
</td>
<td class="TableText" bgcolor="#CCCCCC">
<div>Diameter of tailstock quill</div>
</td>
<td class="TableText">
<div>2-3/8"</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Taper of tailstock quill center</div>
</td>
<td class="TableText">
<div>MT #4</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Max. travel of tailstock quill</div>
</td>
<td class="TableText">
<div>4-13/16"</div>
</td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="2" bgcolor="#333333">
<div><span style="color: #ffffff;"><strong>MOTORS</strong></span></div>
</td>
<td class="TableText" bgcolor="#CCCCCC">
<div>Power of main motor</div>
</td>
<td class="TableText">
<div>7-1/2 HP</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Power of coolant pump</div>
</td>
<td class="TableText">
<div>1/8 HP</div>
</td>
</tr>
<tr>
<td class="Title_white_bold" rowspan="2" bgcolor="#333333">
<div><span style="color: #ffffff;"><strong>MISCELLANEOUS</strong></span></div>
</td>
<td class="TableText" bgcolor="#CCCCCC">
<div>Overall dimensions approx.<br> (L x W x H)</div>
</td>
<td class="TableText">
<div>86" x 41" x 53"</div>
</td>
</tr>
<tr>
<td class="TableText" bgcolor="#CCCCCC">
<div>Net weight, approx (lbs.)</div>
</td>
<td class="TableText">
<div>4,100</div>
</td>
</tr>
</tbody>
</table>
<p><b><br>FEATURES:</b></p>
<ul><li>5 HP Main Motor (7-1/2 HP Optional)</li><li>One-piece cast iron base</li><li>No change gears required</li><li>12 Speeds from 25 - 2,000 RPM</li><li>D1-6 Spindle with 2-9/32" bore</li><li>60 kinds of inch threads from 112-2 TPI</li><li>Main spindle hardened & precision ground</li><li>Bed made of fine grain high tensile cast iron</li><li>Bedways induction hardened & precision ground</li><li>All gears & shafts hardened & precision ground</li><li>Main spindle supported at 3-point by precision bearings</li></ul>
<p><strong>STANDARD EQUIPMENT:</strong></p>
<ul><li>Follow Rest</li><li>14" Face Plate</li><li>7-1/2" Steady Rest</li><li>10" 3-Jaw Chuck</li><li>12" 4-Jaw Chuck</li><li>Operation and Parts Manuals</li><li>Coolant System</li><li>Halogen Work Light</li><li>Removable Gap</li><li>4-way Tool Post</li><li>Thread Chasing Dial</li><li>Hand Oil Pump for Ways</li><li>Centers and Sleeve</li><li>Tool Kit wih Tools</li><li>Automatic Kick-Out Longitudinal Carriage Stop</li><li>Full Length Foot Brake</li><li>Full Length Splash Guard</li></ul>
