<p><b>SPECIFICATIONS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Swing over bed</div></td>
<td width="257" class="TableText"><div align="center">14"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Swing over cross slide</div></td>
<td class="TableText"><div align="center">8-13/16"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Center height </div></td>
<td class="TableText"><div align="center">7"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Admits between</div></td>
<td class="TableText"><div align="center">750mm (30") or 1000mm (40")</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Spindle bore</div></td>
<td class="TableText"><div align="center">1-1/2"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Spindle nose </div></td>
<td class="TableText"><div align="center">D1-4 or D1-5</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Taper in nose</div></td>
<td valign="top" class="TableText"><div align="center">No 5 Morse</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Speeds number</div></td>
<td class="TableText"><div align="center">8</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Speeds range </div></td>
<td class="TableText"><div align="center">70-2000 r/min</div></td>
</tr>
<tr>
<td width="257" bgcolor="#CCCCCC" class="TableText"><div align="center">Cross slide travel </div></td>
<td class="TableText"><div align="center">170mm (6-11/16")</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Compound rest travel</div></td>
<td class="TableText"><div align="center">95mm (3-9/16")</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Lead screw thread </div></td>
<td class="TableText"><div align="center">8T.P.I. or 3mm pitch</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Feed rod diameter </div></td>
<td class="TableText"><div align="center">3/4"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Cutting tool max section</div></td>
<td class="TableText"><div align="center">5/8" x 5/8"</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Threads imperial pitches </div></td>
<td class="TableText"><div align="center">42 Nos. 4-112T.P.I</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Threads metric pitches</div></td>
<td class="TableText"><div align="center">44 Nos. 0.1-7mm</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Threads diametral pitches </div></td>
<td class="TableText"><div align="center">25 Nos. 16-112DP</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Threads module pitches </div></td>
<td class="TableText"><div align="center">34 Nos. 0.1-1.75MP</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Longitudinal feeds imperial </div></td>
<td class="TableText"><div align="center">24 Nos. 0.00168-0.1175"/rev</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Longitudinal feeds metric </div></td>
<td class="TableText"><div align="center">24 Nos. 0.046-3.249 mm/rev</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Cross feeds imperial </div></td>
<td class="TableText"><div align="center">32 Nos. 0.00046-0.03231"/rev</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Cross feeds metric </div></td>
<td class="TableText"><div align="center">24 Nos. 0.01-0.703 mm/rev</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Quill diameter </div></td>
<td class="TableText"><div align="center">32mm(1-1/4") or 42mm (1-21/32")</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Quill travel </div></td>
<td class="TableText"><div align="center">100mm (3-15/16")</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Quill taper </div></td>
<td class="TableText"><div align="center">Quill taper </div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Main motor power </div></td>
<td class="TableText"><div align="center">2 HP, 220V, 1ph or 3ph (specify)</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Coolant pump power</div></td>
<td class="TableText"><div align="center">1/16 HP</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">NG/GW (kg)</div></td>
<td class="TableText"><div align="center">510/630 or 540/645</div></td>
</tr>
<tr>
<td bgcolor="#CCCCCC" class="TableText"><div align="center">Packing size (cm)</div></td>
<td class="TableText"><div align="center">168 ×76 ×153 (750mm) <br>
or 193×76×153 (1000mm)</div></td>
</tr>
</tbody>
</table>
<p><b><br>FEATURES:</b></p>
<ul><li>No change gear in tool box.</li><li>The thread category complete, not only cutting metric thread and imperial thread, but also cutting diametric thread and module thread. </li><li>Minimum Cross feed 0.01mm/rev, Minimum Longitudinal feed 0.046mm/rev.</li><li>No remove gap</li><li>Has no taper turn attachment</li></ul>
<p><strong> STANDARD EQUIPMENT: </strong></p>
<ul><li> Reduction Sleeve 5/3# </li><li> Center MT3#(Dead Center, Alloy Center) </li><li> Three Jaw Chuck 160mm </li><li> Four Jaw Chuck </li><li> Chip Tray </li><li> Splash Guard </li><li> Tool Box & Tools 1set </li><li> Face Plate </li><li> Steady Rest </li><li> Follow Rest </li><li> Brake </li><li> Coolant System </li><li> Work Light</li></ul>
