<p><b>SPECIFICATIONS:</b></p>
<table cellspacing="0" cellpadding="0" border="1" width="520" class="TableText">
<tbody>
<tr bgcolor="#333333" class="Title_white_bold">
<td width="257"><div align="center"><span style="color: rgb(255, 255, 255);"><b>MODEL</b></span></div></td>
<td width="257"><div align="center"><span style="color: rgb(255, 255, 255);"><b>J-2500</b></span></div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Part #</div></td>
<td><div align="center">354400</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Type</div></td>
<td><div align="center">15" Floor</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Drills to Center of Circle (in)</div></td>
<td><div align="center">15</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Drilling Capacity Cast Iron (in.)</div></td>
<td><div align="center">5/8</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Drilling Capacity Mild Steel (in.)</div></td>
<td><div align="center">1/2</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Quill Diameter (in.)</div></td>
<td><div align="center">1-7/8</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Quill Travel (in.)</div></td>
<td><div align="center">3-1/8</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Spindle Taper</div></td>
<td><div align="center">2 MT</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Number of Spindle speeds</div></td>
<td><div align="center">12</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Range of Spindle Speeds (RPM)</div></td>
<td><div align="center">250, 340, 390, 510, 600, 650, 990, 1550, 1620, 1900, 2620, 3100 </div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Overall Table Size (in.)</div></td>
<td><div align="center">10 x 10</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Column Diameter (in.)</div></td>
<td><div align="center">2-7/8</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Distance Column to Spindle (in.)</div></td>
<td><div align="center">N/A</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Base Size (in.)</div></td>
<td><div align="center">11 x 19-1/2</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Spindle Distance to Base (in.)</div></td>
<td><div align="center">48-3/4</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Motor</div></td>
<td><div align="center">3/4 HP, 115V, 1 Ph</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Overall Dimensions (in.)</div></td>
<td><div align="center">26 x 13-3/8 x 63-1/2</div></td>
</tr>
<tr>
<td bgcolor="#cccccc"><div align="center">Weight (lbs.)</div></td>
<td><div align="center">167</div></td>
</tr>
</tbody>
</table>
<p><b><br>FEATURES:</b></p>
<ul><li>Accuracy, stability and versatility are the benchmark features of the JET 15" and 20" Drill Presses. This high quality line of JET Drill Presses offer a greater range in spindle speeds than other machines of this class. JET backs their machines with the industry-leading Two Year Warranty.</li><li>3-1/8" stroke for deep hole applications</li><li>Cast iron head</li><li>Constructed to provide a solid base for drilling</li><li>Large ground steel column for maximum head and table support</li><li>Large quill allows greater accuracy</li><li>Telescoping safety spindle guard</li><li>The enclosed spindle assembly is supported by four permanently lubricated ball bearings for greater precision and accuracy</li></ul>
