<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Capacity
</div>
</td>
<td width="257" class="TableText">
<div align="center">4-1/2 in. pipe and square
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" width="257" class="TableText">
<div align="center">Motor
</div>
</td>
<td class="TableText">
<div align="center">5HP, 3ph, 220 or 440 volt, 3450 RPM <br>
(specify voltage)
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">3PH amp draws
</div>
</td>
<td class="TableText">
<div align="center">230V 12 amps and 440V 6 amps
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">1PH amp draw
</div>
</td>
<td class="TableText">
<div align="center">19.5 amps
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Mitres - left and right
</div>
</td>
<td class="TableText">
<div align="center">45 degrees
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Air over oil
</div>
</td>
<td class="TableText">
<div align="center">0-12 FPM
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">PSI Required
</div>
</td>
<td class="TableText">
<div align="center">40-50
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Spindle Arbor
</div>
</td>
<td class="TableText">
<div align="center">1 in.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Spindle Speed
</div>
</td>
<td class="TableText">
<div align="center">4,400 RPM
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" width="257" class="TableText">
<div align="center">Weight
</div>
</td>
<td class="TableText">
<div align="center">750 lbs.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Shipping dimensions
</div>
</td>
<td class="TableText">
<div align="center">L 44 x W 40 x H 65 in.
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p><p><strong>WARRANTY: 1 YEAR</strong> – Parts</p><ul>
<li>HSM14 14 inch high speed non-ferrous mitre saw is designed to material such as brass, aluminum and plastic with the correct high speed blade quick and efficient with right high speed blade.</li>
<li>Made in the USA</li>
<li> For non-ferrous only</li>
<li>Magnetic controls with 24V low voltage protection at on/off push buttons.</li>
<li> Semi-automatic</li>
<li>Double v-belt sdrive.</li>
<li>All steel construction!</li>
<li>Double air vises that open up 6" with movement Left/right and front/back.</li>
<li>OSHA safety blade guard (Clam Shell Guard).</li>
<li><strong>WHAT THE HSM14 14 INCH NON-FERROUS MITRE SAW CAN CUT:</strong>
<ul>
<li>Aluminum</li>
<li>Brass</li>
<li>Bronze</li>
<li>Plastic/PVC</li>
</ul>
</li>
</ul>
<p><b>OPTIONAL ITEMS:</b></p>
<ul>
<li>PH-14: Power down feed: $3,100.00 </li>
<li>AV-18: Air Vise: $890.00</li>
</ul>
