<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr>
<td bgcolor="#cccccc" width="257" class="TableText">
<div align="center">Capacity
</div>
</td>
<td width="257" class="TableText">
<div align="center">2-1/2 in.solid, 3 in.shapes
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" width="257" class="TableText">
<div align="center">Motor
</div>
</td>
<td class="TableText">
<div align="center">5 HP, 3 PH, 1725 RPM TEFC motor
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Saw FLA’s for 60HZ
</div>
</td>
<td class="TableText">
<div align="center">230V 13.4 amps and 460V 6.7 amps
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Wheel size
</div>
</td>
<td class="TableText">
<div align="center">14 in. (blade not included)
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Spindle arbor
</div>
</td>
<td class="TableText">
<div align="center">1 in.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Spindle Speed
</div>
</td>
<td class="TableText">
<div align="center">2200 RPM
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Adjustable feed rate
</div>
</td>
<td class="TableText">
<div align="center">0-12 FPM
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">Flood coolant
</div>
</td>
<td class="TableText">
<div align="center">10 gal., 1/3 HP
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" class="TableText">
<div align="center">External Dimensions
</div>
</td>
<td class="TableText">
<div align="center">L 43 x W 26 x H 60 in.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" width="257" class="TableText">
<div align="center">Shipping Dimensions
</div>
</td>
<td class="TableText">
<div align="center">L 58 x W 58 x H 77 in.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" width="257" class="TableText">
<div align="center">Shipping Weight
</div>
</td>
<td class="TableText">
<div align="center">1,000 lbs.
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul>
<li><span data-offset-key="abr25-0-0">The K12-14MS 14 inch metallurgical saw is an industrial lab tool for used steel sample cutting</span><span data-offset-key="abr25-1-0">. This wet saw can produce clean and bright cuts when using the correct cutoff wheel for your steel.</span></li>
<li><span data-preserver-spaces="true">This lab saw is designed for the following:</span>
<ul>
<li><span data-preserver-spaces="true">Heat treat penetration</span></li>
<li><span data-preserver-spaces="true">Weld check penetration</span></li>
<li><span data-preserver-spaces="true">Destructive testing</span></li>
<li><span data-preserver-spaces="true">Hardness test</span></li>
</ul>
</li>
<li>Semi-automatic air/oil power down feed</li>
<li>Adjustable feed rate 0-12 FPM, Momentary rapid override for rapid approach</li>
<li>Dual moveable 4" screw vises</li>
<li>Magnetic switch, low-voltage protection at the switch, 24V</li>
<li>Internal halogen light – 24V</li>
<li>1" wheel arbor, 12" or 14" blade, (not included), Optional 1.25" /32mm arbor</li>
<li>Dual coolant nozzles</li>
<li data-block="true" data-editor="tp46" data-offset-key="bgs3a-0-0">Oscillation</li>
<li>Steel enclosure with hinged doors</li>
<li><span data-offset-key="an21c-0-0">Removable maintenance access panel </span><span data-offset-key="an21c-0-1">(rear of enclosure</span>)</li>
<li>Removable infeed and outfeed panels</li>
<li>Made in USA!</li>
<li>The K12-14MS 14 inch industrial wet abrasive metallurgical cutoff saw is used in the following industries: Energy, Oil/Natural Gas, Met Labs, Petro/Chemical, Knife Manufacturing, Automotive, Metal Foundries, as well as many other Manufacturing and Fabrication environments.</li>
</ul>
<p><b>OPTIONAL ITEMS:</b></p>
<ul>
<li><span data-offset-key="2i3v2-0-0">710-052 door safety interlocks</span>: $CALL</li>
<li><span data-offset-key="a73gi-0-0">TS-14 t-slot table</span>: $CALL</li>
<li><span data-offset-key="8j0vs-0-0">AV-14 air-operated jawed vise</span>: $860.00</li>
<li><span data-offset-key="7c37e-0-0">KW-1 spindle wrench</span>: $CALL</li>
</ul>
