<table border="1" cellspacing="0" cellpadding="0" width="520">
<tbody style="text-align: center;">
<tr>
<td class="TableText1" width="257" bgcolor="#cccccc">
<div>Cap. to Mild Steel (A36)
</div>
</td>
<td class="TableText1" width="257">
<div>1-1/2" x 10'
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Cap. to Stainless steel
</div>
</td>
<td class="TableText1">
<div>1" x 10'
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Shearing tons available
</div>
</td>
<td class="TableText1">
<div>475
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div># of hold down cylinders
</div>
</td>
<td class="TableText1">
<div>11
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Bore of hold downs
</div>
</td>
<td class="TableText1">
<div>6"
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Hold down tons of force
</div>
</td>
<td class="TableText1">
<div>340
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Weight (lbs.)
</div>
</td>
<td class="TableText1">
<div>110,000
</div>
</td>
</tr>
<tr>
<td class="TableText1" bgcolor="#cccccc">
<div>Backgauge Travel
</div>
</td>
<td class="TableText1">
<div>48"
</div>
</td>
</tr>
</tbody>
</table>
<p>*Other Lengths of 1-1/2" Shears Are Available Per Special Quote
</p>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 5 YEAR</strong> – <strong>STANDARD </strong>Parts & Limited Onsite Labor
</p>
<ul>
<li>Manual, side adjustable, quick-change blade gap adjustment</li>
<li>PLC controlled backgauge</li>
<li>A660 bronze bearings guaranteed for 5 years based on a 24 hour workday. These bearings easily last 15-20 years and the bronze material is always readily available.</li>
<li>Under 3,000 P.S.I. system pressure that provides substantially longer system life.</li>
<li>Extremely heavy-duty hold downs. Fewer hold downs = less maintenance. Hold down pressure is adjustable for your sensitive material.</li>
<li>Extremely heavy duty, precision tables designed to provide the least amount of deflection and to last generations</li>
<li>Incredibly strong gusseted table providing decades of reliable performance</li>
<li>Complete O.S.H.A. and ANSI B11.4 Compliance</li>
<li>Positive mechanical tapered gibbs for smooth uniform gap adjustment</li>
<li>Easy to understand mechanical gap indicators showing exact gap placement and infinite adjustment</li>
<li>Incredibly simple, easy to troubleshoot hydraulic system is fully covered by our 5 year warranty and is comprised of all readily available components</li>
<li>Lifetime Parts Availability: Every component on machine is available from your local suppliers giving you a lifetime of productivity and parts</li>
<li>Shadow light for precise shearing line</li>
</ul>
<p><strong>STANDARD EQUIPMENT:</strong>
</p>
<ul>
<li>PLC Touch Screen Control</li>
<li>36” or 48” Travel EXTREMELY Heavy Duty Backgauge</li>
<li>Fully Loaded, Extremely Heavy Duty Table</li>
<li>All 1/4” and 3/8” shears that are 12’ and shorter come standard with a manual side adjustable gap adjustment.</li>
</ul>
<p><b>OPTIONAL ITEMS:</b></p>
<ul>
<li>Squaring Arms</li>
<li>Swing Stops For Squaring Arms</li>
<li>Disappearing/Gravity Stops for T-Slots</li>
<li>Support Arms</li>
<li>T-Slot Across Front Edge of Table</li>
<li>Ball Transfers in Table</li>
<li>Additional T-Slots in Table</li>
<li>Additional Hand Slots in Table</li>
<li>Protractor</li>
<li>Full Nylatron Table Cover</li>
<li>48” travel in lieu of 36”</li>
<li>Automatic Power Swing-Away Backgauge</li>
<li>High Speed Hydraulic System</li>
<li>Impact Pads for Hold Down Cylinders</li>
<li>Additional Hold Downs</li>
<li>Independent Activation of Hold Downs</li>
<li>Automatic Lubrication System</li>
<li>2 Position Power Rake Adjustment</li>
<li>Infinitely Variable Power Blade Gap Adjustment</li>
<li>Paint Color</li>
<li>Shear Blades</li>
<li>Oil Cooler</li>
<li>Conveyors</li>
<li>Stacker</li>
<li>Pneumatic Sheet Supports</li>
<li>Onsite Training</li>
<li>Light Curtain Safety Barriers</li>
<li>Physical Barriers/Cages</li>
<li>Compliance Options</li>
<li>CNC Square Gauge Systems</li>
<li>*Other lengths of Shears and Special Process/Cut To Length Line Shears Are Available Per Special Quote</li><li><strong>FOR MORE INFORMATION ON OPTIONS CONTACT SIERRA VICTOR MACHINERY</strong></li>
