- Description
- 10 HP Main Motor
- One-piece cast iron base
- D1-8 Spindle with 3-1/8" bore
- No change gears required
- 12 Speeds from 45-1,600 RPM
- 60 Kinds of inch threads from 112-2 TPI
- 47 kinds of metric threads from 0.2 - 14mm
- Main spindle hardened & precision ground
- Bed made of fine grain high tensile cast iron
- Bedways induction hardened & precision ground
- All gears & shafts hardened & precision ground
- Main spindle supported at 3-point by precision bearings
- 3 JAW CHUCK
- 4 JAW CHUCK
- FACE PLATE
- STEADY REST W/ ROLLER JAWS
- FOLLOW REST
- GAP
- 4 WAY TOOL POST
- THREADING CHASING DIAL
- ( 2 ) DEAD CENTERS
- REDUCING SLEEVE
- FULL LENGTH SPLASH GUARD
- ONE PIECE CAST IRON BASE
- FOOT BRAKE
- HALOGEN WORK LIGHT
- COOLANT SYSTEM
- LEVELING PADS
- 4 POSITION AUTO KICK-OUT LONGITUDINAL CARRIAGE STOP
- TOOL BOX
- TAPER TURN ATTACHMENT
- Manufacturer
- Specifications
- Options/Accessories
- 10" LARGE STEADY REST W/ ROLLER JAWS
- 5C HAND LEVER TYPE COLLET CLOSER "JFK" USA
- 5C COLLET CHUCK (FRONT OPERATE) D1-6 MOUNT
- DIGITAL READOUT: " NEWALL DP-700 " OR " ACU-RITE " OR " UNIQ IMPORT"
- Custom Freight
BIRMINGHAM 22" x 120" Precision Gap Bed Lathe YCL-22120
STANDARD EQUIPMENT:
ITEM: Precision Gap Bed Lathe
MANUFACTURER: BIRMINGHAM
MODEL: YCL-22120
Manufacturer:
Birmingham
Lathes
Lathe Size:
22" x 120"+
Lathe Type:
Precision
Machine Type
Machine Category:
Lathes
Machine Sub-Category:
Gap Bed
MODEL |
YCL-22120 |
|
CAPACITY |
Max. swing over bed |
22" |
Distance between centers |
120" |
|
Max. effective cutting length |
116" |
|
Max. swing over cross slide |
13-3/4" |
|
Max. swing in gap |
31" |
|
Effective length in gap |
6" |
|
Width of bed |
13-3/4" |
|
HEADSTOCK |
Spindle nose |
D1-8 |
Diameter of spindle thru bore |
3-1/8" |
|
Taper of spindle center |
MT #7 / MT # 5 |
|
Spindle speeds, 12 steps |
25, 35, 55, 80, 120, 170, 235, 350, 525, 700, 1100, 1600 RPM |
|
FEEDS & THREADS |
Longitudinal feeds |
35 kinds, 0.0022" - 0.0612"/rev. |
Cross feeds |
35 kinds, 0.00048" - 0.01354"/rev. |
|
Metric threads |
47 kinds, 0.2 - 14mm |
|
Inch threads |
60 kinds, 112 - 2 TPI |
|
Module threads |
39 kinds, 0.1 - 7mm |
|
Diametral pitch threads |
50 kinds, 4 - 112 DP |
|
CARRIAGE |
Max. travel of cross slide |
12-15/16" |
Max. travel of top slide |
5-1/8" |
|
4-way tool post size |
1" x 1" |
|
Longitudinal leadscrew dia./pitch |
Dia 1-5/8" / 4 TPI |
|
TAILSTOCK |
Diameter of tailstock quill |
3" |
Taper of tailstock quill center |
MT #5 |
|
Max. travel of tailstock quill |
7" |
|
MOTORS |
Power of main motor |
10 HP, 230/460V / 60Hz, 3 Phase Prewired 230V |
Power of coolant pump |
1/8 HP, 230/460V / 60Hz, 3 phase Prewired 230V |
|
MISCELLANEOUS |
Overall dimensions approx. (L x W x H) |
154" x 46" x 58" |
Net weight, approx (lbs.) |
7,600 |
|
Gross weight, approx. (lbs.) |
8,600 |
Specifications and design are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
CALL FOR PRICE:
