- Description
- This durable, easy-to-use plate roll will last for many years in small to medium shops. Its 3 hydraulically driven rolls can handle maximum capacity with ease and finish jobs faster.
- 4’ forming width.
- 3 gauge (¼”) mild sheet steel capacity.
- 3 hp motor runs on 220-volt 3-phase power.
- Large planetary gearbox, connected to main motor, drives the top and bottom rolls.
- Industrial-grade hydraulic system drives all 3 rolls.
- Movable control pedestal includes foot pedals to run the rolling and buttons to move the forming roll up and down.
- Easy to operate: insert material, turn the handwheel to bring up the pinch roll, then use the foot pedals to start rolling.
- Just flip a switch to bring the back roll up at an angle for coning.
- Quick-release mechanism on the top roll makes it easy to slide off the finished work.
- Digital readout tracks the position of the back roll so you can make repeatable bends.
- Robust welded steel frame maintains accuracy and rigidity by keeping the rolls in alignment.
- Dual emergency stop cables are located on the front and back of the machine for your safety.
- Covered by a 1-year parts warranty.
- Includes lifetime technical support by phone from a team with hands-on machine experience.
- Manufacturer
- Specifications
- Required products
BAILEIGH 4' x 1/4" Plate Roll PR-403
ITEM: 4' x 1/4" (3 ga) Single Pinch Hydraulic Plate Roll
MAUNFACTURER: BAILEIGH
MODEL: BA9-1006481
Manufacturer:
Baileigh Industrial
Machine Type
Machine Category:
Plate Bending Rolls
Power Source:
Hydraulic
Metalworking
Material Length:
4 ft (48 in+)
Mild Steel Capacity:
3 ga (1/4")
Forming Width
|
48"
|
Upper Roll Diameter
|
5.91"
|
Minimum Forming Diameter
|
8.86"
|
Roll Adjustment Back
|
Hydraulic
|
Roll Speed
|
4.67 rpm.
|
Motor
|
3 hp
|
Power Requirement
|
220V / 3-phase
|
Shipping Dimensions (L / W / H)
|
83" x 32" x 52"
|
Shipping Weight
|
4,180 lbs
|
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
