Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 5 YEAR – STANDARD Parts & Limited Onsite Labor

• CUSTOMIZATION:
• We welcome requests for customization of any of our machines. Many aspects of all machines can be contoured to match your requirements.
• HYDRAULIC SYSTEMS:
• We offer conventional and proportional hydraulic systems engineered to your requirements.
• START UP/TRAINING:
• Onsite training at the customer’s facility is available optionally. Due to the simplicity of the operation of our base model presses, onsite training is rarely needed. Onsite training is included with the purchase of the optional PLC ram control. Please note that all machines must be fully installed, rigged in place, leveled/bolted down, oil in reservoir and hooked up electrically prior to the arrival of the technician.
• EXTENDED WARRANTY SERVICE:
• This package includes all the features of our standard warranty plus: A 7 year parts in lieu of standard 5 year parts warranty
• T-SLOT CONFIGURATION:
• (NOTE) (2) 5/8” t-slots are standard on all presses in the bed and ram (running left to right) T-slots sizes are available in 5/8”, 3/4” or 1” T-slots in the bed and/or ram. Special T-slot sizes are available
• LUBRICATION SYSTEMS:
  • Manifold Lubrication System - Brings all lubrication points to one area.
  • Automatic Lubrication System - Automatically lubricates machine with EP-1 grease. Includes warning light when oil is low & auto-shutoff
• PNEUMATIC QUICK-CHANGE TOOLING SYSTEM:
• Air actuated die lifters in press bed for easy and quick die change and quick set ups.
• SAFETY:
  • Hand/Foot Safety Sequence with Footswitch - Allows operator to use (2) hand pedestal control until “slow down” speed at which time the footswitch can used for remainder of stroke.
  • Light Curtain Safety Barrier - Infra-Red light curtain across front of press that stops operation of machine if light curtain is broken. Blanking with programmability included by request.
  • Interlocking Side barriers - Physical barriers for protecting operator that shut the machine down if removed. Can be alone or used in conjunction with light curtains
  • Additional Control Stations and/or Pedestals - NOTE: (1) Palm button station is included with all presses. Palm buttons can be mounted to bed/ram or additional pedestals on floor for multiple operators
  • Gear Lock Safety Systems - Interlocking mechanical gear system that provides physical stops to prevent ram dropping.
• OPERATIONAL PREFERENCES:
  • Pressure Reversal of Ram - Allows the ram to return to top of stroke once a pre-set pressure/tonnage is achieved.
  • Auto Cycle Remote - Allows ram to stoke automatically without operator actuation. NOTE: requires safety barrier or light curtain.
  • Dwell Under Tonnage - Allows machine to “dwell” with required tonnage for a predetermined amount of time.
  • Coil Line Processing and Material Feed Equipment - We work with providers of process lines and feeding equipment for all levels of production.
• STROKE DAMPENERS - When additional punching capacity is required, this feature helps get more punching tonnage without shocking the hydraulic system
• DIE CUSHIONS:
• Aids in forming processes and for drawing and/or part ejection.
• REMOVABLE BED/BOLSTER:
• Recommended for machines with die cushions to allow access to die cushion for maintenance. Not available with AM/CM models.
• RAM CONTROL
• As standard the ram travel is controlled via simple mechanical limit switches that control open height, speed change point and the lower limit via a micrometer.
• Digital Readout (Non-Programmable)
• Shows ram location while using the standard mechanical limit switches
• PLC/Programmable Ram Control:
• Controls base functions of press.
  Includes onsite training at customer’s facility (contiguous U.S.).
  • Touchscreen display.
  • 200 programmable jobs.
  • Custom features available.
  • Onsite training included.
  • Controls open height, speed change point and lower limit via precision digital encoder.
  • Programmable tonnage.
  • Special programming functions to match your needs are available.
  • Mitsubishi PLC is our recommended control but other brand PLC’s can be quoted.
• HIGH SPEED HYDRAULIC SYSTEMS:
  • ADDITIONAL OPEN HEIGHT AND/OR ADDITIONAL STROKE
  • ADDITIONAL THROAT DEPTH (C-FRAME MODELS ONLY)
  • Note: Stroke options increases overall height and does not automatically increase open height or closed height. Also, extra open height does not automatically increase stroke. All options quoted may increase dimensions/weight of machine.
• OTHER OPTIONS AVAILABLE:
• Safety equipment to user specification
• Special machining
• Special platens
• Air counterbalance
• Special electrics
• Bed/Ram customization
• UL/CSA and other certifications—As standard all components are UL508A compliant
• Special single paint color
• Other options available per customer request
• Scrap chutes and knockouts
