<table cellspacing="0" cellpadding="0" border="1" width="520">
<tbody style="text-align: center;">
<tr>
<td bgcolor="#333333" valign="middle" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>MODEL</strong></span>
</div>
</td>
<td bgcolor="#333333" valign="middle" class="Title_white_bold">
<div align="center"><span style="color: rgb(255, 255, 255);"><strong>HS-1214M</strong></span>
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" width="257" valign="middle" class="TableText">
<div align="center" class="TableText">
<div align="center">Cutting Capacity: Mild Steel
</div>
</div>
</td>
<td width="257" valign="middle" class="TableText">
<div align="center">12 ft x 14 ga.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Cutting Capacity: Stainless Steel
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">12 ft x 18 ga.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Cutting Capacity: Soft Aluminum</div>
</td>
<td valign="middle" class="TableText">
<div align="center">12 ft x 10 ga.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Min. Thickness
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">22 ga.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" width="257" valign="middle" class="TableText">
<div align="center">Blade length
</div>
</td>
<td width="257" valign="middle" class="TableText">
<div align="center" class="TableText">
<div align="center">12 ft = 144 in.
</div>
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Strokes per minute
</div>
</td>
<td valign="middle" class="TableText">
<div align="center" class="TableText">
<div align="center">10-12
</div>
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Throat depth
</div>
</td>
<td valign="middle" class="TableText">
<div align="center" class="TableText">
<div align="center">18 ft
</div>
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Worktable height
</div>
</td>
<td valign="middle" class="TableText">
<div align="center" class="TableText">
<div align="center">34-1/2 in.
</div>
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Front support arm
</div>
</td>
<td valign="middle" class="TableText">
<div align="center" class="TableText">
<div align="center">24 in.
</div>
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Back gauge
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">24 in. Manual Back gauge
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Blade rake angle
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">2 degree
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Oil tank cap.
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">26 Gal.
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Main motor
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">10 HP, 220V/35A - 440V/20A
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center">Machine weight
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">9,150 lbs
</div>
</td>
</tr>
<tr>
<td bgcolor="#cccccc" valign="middle" class="TableText">
<div align="center" class="TableText">
<div align="center">Machine dimensions
</div>
</div>
</td>
<td valign="middle" class="TableText">
<div align="center">195 x 44 x 66 in.
</div>
</td>
</tr>
</tbody>
</table>
<p>Specifications are subject to change without notice.
</p>
<p>NOTE: Data is provided by the manufacturer.
</p>
<p><strong>WARRANTY: 1 YEAR</strong> – Parts
</p>
<ul>
<li>ISO 9001 certified</li>
<li>Taiwan machines</li>
<li>Quick Change Blade Gap Adjustment</li>
<li>CE standard “OMERO” electric control system</li>
<li>Meet OSHA safety standard code</li>
<li>Shadow line for accurate straight cutting</li>
<li>Adjustable cutting length and stroke</li>
<li>Ball transfer plates on worktable for easy loading workpiece</li>
<li>Well balanced and sturdy all steel machine frame</li>
<li>German made Hydraulic logic system centrally located and quiet</li>
<li>Hydraulic hold-downs with anti-mar neoprene</li>
<li>Shear blades are high grade carbon/chrome alloy steel and hardened to 60 HRC, 2-edge indexable upper blade and 2-edge indexable bottom blade </li>
<li>Full length viewable safety finger guard to protect operator from cutting hazard</li>
<li>Removable safety foot pedal, automatic blade raise up on removal of foot from pedal</li>
<li>Hydraulic, electrical overload protection</li>
<li>Compact operator control panel</li>
<li>All motors are overload protected & low voltage control system</li>
<li>Jog or continuous auto cycle cutting operation modes</li>
<li>One year industrial warranty for parts</li>
<li>*This machine is compatible with a phase converter. Please note that the phase converter must be installed by GMC Machine Tools to ensure warranty coverage. Once the machine is received and the phase converter is installed by us, it will be ready for use. For more information or if you have any further questions or need assistance, feel free to contact us.</li>
</ul>
<p><strong>EQUIPPED WITH:</strong>
</p>
<ul>
<li>24” manual back gauge ( one side wheel drive )</li>
<li>1 each 60” squaring arm with inlaid inch/metric dual scale</li>
<li>Quick change blade gap adjustment (BGA)</li>
<li>Shadow line for accurate straight cutting</li>
<li>Material support and drop back chuter</li>
<li>Upper and bottom blade set with 2-edge on bottom & 2-edge on upper</li>
<li>2 each 24” front support arms</li>
<li>Hydraulic hold-downs with anti-mar neoprene</li>
<li>Full length viewable finger guard</li>
<li>Removable safety foot pedal</li>
<li>Tool box</li>
</ul>
<p><b>OPTIONAL ITEMS:</b></p>
<ul>
<li>Safety fence for enclosure of the back side of the machine</li>
</ul>
